Varun Sheets and Plates, a reputable manufacturer and supplier based in Dubai, UAE, specializes in high-quality Stainless Steel 904L Angles that are engineered for exceptional corrosion resistance and mechanical strength. With a strong commitment to quality and compliance with international standards, Varun provides SS 904L Angles that find applications in marine, chemical, and structural sectors. These angles are crafted using cutting-edge technology to guarantee precise dimensions and a long lifespan. Offering tailored solutions, timely delivery, and competitive pricing, Varun Sheets and Plates is a dependable partner for industries in need of high-performance stainless steel components.
Stainless Steel 904L Angles are made up of iron, 19–23% chromium, 23–28% nickel, 4–5% molybdenum, along with trace amounts of copper and carbon. This low-carbon, high-alloy austenitic stainless steel boasts remarkable resistance to strong reducing acids, such as sulfuric acid. Its mechanical properties include a tensile strength ranging from 490 to 710 MPa, a yield strength of 220 MPa, and an elongation of about 35%. With a density of 8.0 g/cm³, along with excellent weldability and formability, SS 904L Angles are perfect for applications where both corrosion resistance and structural integrity are crucial.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| >SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 904L angle offers many advantages, including excellent corrosion resistance, especially in acidic environments, which makes it ideal for applications such as chemical processing, seawater handling and more etc. Highly resistant to pitting and crevice corrosion, ensuring durability in extreme conditions. The alloy offers excellent weldability and formability, making it versatile for a variety of structural applications. With increased strength and durability, the stainless steel 904L Angle maintains its integrity under extreme temperatures and pressures. The low carbon content reduces carbide precipitation and increases corrosion resistance in high-temperature environments.
These Stainless Steel 904L Angles are widely utilized in challenging and corrosive environments. In the chemical and petrochemical sectors, they are essential for equipment like heat exchangers, tanks, and process piping due to their ability to withstand acid attacks. In the marine industry, 904L Angles are employed for structural components that are regularly exposed to saltwater and chloride-rich conditions. They also play a vital role in pulp and paper facilities, pollution control systems, and pharmaceutical manufacturing. Thanks to their outstanding formability and strength, they are ideal for architectural and structural frameworks that demand durability and resistance to harsh environments.
