Varun Sheets and Plates is a reliable producer and supplier of Stainless Steel 440C Angles in Dubai, UAE, which provides high-strength structural pieces for industrial applications that require high specifications. SS 440C is high-carbon martensitic stainless steel that has excellent hardness, wear resistance, and moderate corrosion resistance. Varun supplies SS 440C angles in various sizes and dimensions made in compliance with international standards like ASTM A276. These angles are extensively utilized in applications where high mechanical strength and durability are critical, used in industries such as tool-making, machinery, defense, aerospace, and heavy machinery manufacturing.
Stainless Steel 440C Angles have about 16–18% chromium and 0.95–1.20% carbon, along with small traces of manganese, silicon, and molybdenum. The high-carbon content makes them susceptible to heat treatment, with a hardness of up to 58–60 HRC. It provides tensile strength of 760–1900 MPa and yield strength of approximately 450 MPa. Although not suited for welding because of its brittleness when hardened, SS 440C exhibits good performance in dry to moderately corrosive conditions. It has excellent edge retention, abrasion resistance, and load-carrying capability, thus being well-suited for heavy-duty structural applications.
| Dimensions | EN, ASME, AISI, BS, JIS, DIN, ASTM, |
|---|---|
| Stainless Steel 440C Round Bar size | Thickness: 2 to 100 milimeter |
| Tolerance | K11, H8, H12, K12, H13, H10, H9, K9, K10, H11, or as per need |
| Stainless Steel 440C Round Bar Form | Round, Rod, T-Bars, Channel Bars, Precision Ground Bars, Flat Bars, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Threaded, Hex (A/F), Rectangle, Half Round Bars, Profiles, Billet, Ingot, Forging, I/H Bars etc. |
| Flat bar size | Dia: 3-~800 milimeter |
| Width: 10 – 500 milimeter | |
| size of Stainless Steel 440C Angle bar | 3 milimeter * 20 milimeter* 20 milimeter~12 milimeter* 100 milimeter* 100 milimeter |
| Section bar | 3.0 – 12.0 milimeter thk |
| SS 440C Channel Bar sizes | 5 – 6 milimeter thk, 80 x 40 milimeter – 150 x 75 milimeter section |
| Hollow Bar sizes | 32 milimeter Outside Diameter x 16 milimeter Inside Diameter to 250 milimeter Outside Diameter x 200 milimeter Inside Diameter) |
| Size of Rectangles | 34 x 30 milimeter – 295 x 1066 milimeter |
| Stainless Steel 440C Billet Size | 1/2 – 495 milimeter Diameter |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Finish | Cold (bright) drawn, hot rolled, slit rolled edge, Polish, Bright, peeled, hot rolled annealed, Rough Turned, centreless ground, Centreless Ground, smooth turned, Grinding & Black |
| Technique | Stainless Steel Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Stainless Steel 440C Round Bar Condition | annealed, tempered, Hardened |
| Processing | cutting to 650 milimeter |
|
Stainless Steel 440C |
Max |
Min |
|---|---|---|
|
C |
1.20 |
0.95 |
|
Si |
1.00 |
– |
|
Mn |
1.00 |
– |
|
Ni |
1.00 |
– |
|
Cr |
18.00 |
16.00 |
|
Mo |
0.75 |
0.00 |
|
P |
0.04 |
– |
|
S |
0.03 |
0.15 |
|
Element |
Stainless Steel 440C |
|---|---|
|
Temp°C |
20 |
|
Tensile (UTS)N/mm² |
1965 |
|
0.2% YieldN/mm² |
1896 |
|
Elongation(50.8mm) %) |
2 |
|
HardnessHRc |
57 |
|
Reductionof Area |
10 |
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
|---|---|---|---|
|
Stainless Steel 440C |
1.4125 |
S44004 |
SUS 440C |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 440C angle offers several advantages including high hardness and excellent wear resistance, making it ideal for heavy load and abrasion applications especially in sensitive corrosive And corrosion environments high resistance, due to its high chromium content. The ability to retain energy at high temperatures makes it suitable for high temperature applications. The material is also very durable, making it last longer and less maintenance. Stainless steel 440C angle is commonly used in the manufacture of tool, machine parts and high performance valves. Its strength and durability make it highly reliable in harsh industrial environments.
Stainless Steel 440C Angles are perfect for heavy-duty applications involving high stresses where maximum strength along with abrasion resistance is necessary. They find widespread application in the production of industrial blades, dies, machine parts, and wear-resistant support frames. In aerospace and automotive applications, SS 440C angles find application in mission-critical components subjected to high mechanical stresses and surface wear. They are also appropriate for structural supports in tooling systems, high-precision mechanical devices, and specialized medical equipment. Because they are hard and have great strength, these angles provide long life under severe operating conditions.
