Varun Sheets and Plates is a reliable supplier and manufacturer of Stainless Steel 348H Angles in Dubai, UAE, providing premium structural parts ideal for corrosive and high-temperature applications. SS 348H is an austenitic stainless steel with niobium stabilization and high carbon content, which offers maximum intergranular corrosion resistance and better strength at high temperatures. Varun provides SS 348H angles in different sizes and specifications according to ASTM A240 and A276 standards that cater to industry segments like chemical processing, power generation, heat treatment, and petrochemicals where corrosion resistance and thermal stability are essential.
Stainless Steel 348H Angles consist of 17–20% chromium, 9–13% nickel, and 0.04–0.10% carbon, stabilized with columbium (niobium) and tantalum. The above composition provides resistance to sensitization when welded and high-temperature exposure. SS 348H provides tensile strength of about 515 MPa and yield strength of about 205 MPa. It maintains mechanical properties in continuous service up to 870°C and provides the best resistance to oxidation, creep, and stress rupture and is therefore suitable for high-temperature environments.
Standard – ASTM A240 / ASME SA240, JIS4304-2005, ASTM A167, EN10088-2-2005, GB/T3280-2007, etc
Thickness – 0.3mm – 100mm
Width – 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Length – 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc
Surface – 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Material – Soft, Deep Draw, Extra Deep Draw, Quarter Hard, Half Hard, Full Hard.
Finish – Hot rolled plate (HR), Cold rolled sheet (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA
Form – Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc.
| Grade | Mn | P | C | S | Cr | Si | Ni | Fe | Co |
| SS 348 | 2.0 | 0.045 | 0.080 | 0.030 | 19 | 1.0 | 11 | 66 | 0.2 |
| SS 348H | 2.00 | 0.045 | 0.04-0.10 | 0.030 | 17.00-19.00 | 0.75 | 9.00-13.00 | – | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Rockwell B (HR B) max | Brinell (HB) max |
| 348 | 515 | 205 | 40 | 92/95 | 201/217 |
| 348H | 968 (≥) | 423 (≥) | 32 | 34 | 212 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 348 | 1.4550 | S34800 |
| SS 348H | 1.4961 | S34809 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 348H angle provides excellent resistance to high temperatures, making it ideal for use in hot environments. The presence of niobium increases the resistance to intergranular corrosion, especially in welded structures. The alloy also has excellent oxidation resistance at temperatures up to 800°C (1472°F). It exhibits excellent strength and durability, providing durability in extreme conditions. Stainless steel 348H is extensively used in petrochemical, power generation, heat exchanger and other industries, for reliability and performance in extreme conditions.
Stainless Steel 348H Angles have extensive applications in boilers, heat exchangers, superheaters, chemical tanks, and furnace components owing to their thermal performance. They are also utilized in nuclear and thermal power facilities, drug processing systems, and refinery and reactor machinery, where structural integrity under thermal stress is necessary. Under high-heat conditions with repeated thermal cycling, SS 348H angles offer long-lasting, reliable support with extended service life. Their carbide resistance and weldability make them ideal for heavy-duty structural use where corrosion resistance at high temperatures is needed.
