Varun Sheets and Plates, one of the prominent stainless steel suppliers and manufacturers in Dubai, UAE, provides superior Stainless Steel 202 Angles that are a mix of strength, durability, and affordability. These angles are best suited for general structural uses, railings, furniture frames, and architectural features. Highly formable and offering excellent surface finish, SS 202 Angles from Varun Sheets and Plates are produced in accordance with international standards and as per customer requirements. With a dedication to timely delivery, high quality, and consistent service, the company has gained trust among numerous industries in the UAE and worldwide.
Stainless Steel 202 Angle is an austenitic chromium-nickel-manganese alloy containing about 17–19% chromium, 4–6% nickel, and 7.5–10% manganese. It provides a tensile strength of about 515–750 MPa and a yield strength of about 275 MPa. SS 202 has good formability and toughness, with an average corrosion resistance, especially in indoor and mildly corrosive conditions. It is an economical substitute for SS 304, mainly in applications where extreme corrosion resistance is not a major priority.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 202 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade 202 | C | Mn | Si | P | S | Cr | Ni | N |
| max. | 0.15 | 7.50-10 | 1 | 0.060 | 0.030 | 17- 19 | 4-6 | 0.25 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| 202 | 515 | 275 | 40 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 202 | S20200 | 1.4373 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 202 angle offers many advantages, including excellent corrosion resistance, making it ideal for use in wet and chemical environments It has excellent strength and durability, and ensures performance reliability in construction applications. This alloy is cost-effective compared to higher grades like 304, while still providing high resistance to oxidation and turbidity. Stainless Steel 202 is highly versatile, easy to manufacture and maintain, and provides aesthetic appeal. It is commonly used in the construction, design and construction industry, providing a balance of energy and cost.
| Sizes (all Dimensions in milimeter) | Approx Weight SS Angle Bar (kilogram/meter) | SS 202 Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight SS 202 Angle Bar (kilogram/meter) |
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
Stainless Steel 202 Angles find applications in various industries such as construction, automotive, interior fabrication, and transportation. Common uses include support frames, display stands, decorative trim, storage systems, and railings. Because of its superior weldability and formability, SS 202 can be applied to both industrial and consumer-oriented projects. While they are not optimal for sea or hostile chemical exposure, SS 202 Angles are effective under dry conditions and serve as an affordable and dependable option for structural and architectural applications.
