Varun Sheets and Plates is a prominent Stainless Steel 436 Angles manufacturer and supplier in Dubai, UAE, providing high-quality ferritic stainless steel structural items that are designed for durability, formability, as well as resistance to heat. SS 436 is a modified type of 430 grade that has been enriched with molybdenum to enhance corrosion resistance, particularly against chlorides and other aggressive substances. Varun offers SS 436 angles in different sizes, finishes, and dimensions as per international specifications such as ASTM A240 and A276. Stainless Steel 436 Angles find extensive applications in automobile systems, building structures, and industrial uses exposed to high temperature with demand for robust structural performance.
Stainless Steel 436 Angles consist of around 16–18% chromium, 0.75–1.25% molybdenum, and low carbon composition (max 0.12%), while other additions like titanium or niobium are done for stabilization. This alloy provides better resistance against pitting and crevice corrosion than SS 430 and possesses good thermal conductivity. SS 436 possesses fair mechanical properties with tensile strength between 415–585 MPa and yield strength up to 275 MPa. It also offers superior resistance to oxidation and scaling at high temperatures, making it suitable for thermal cycling environments.
| Specifications | ASTM A240, ASME SA240 |
| Standard | JIS, ASTM, AISI, GB, EN, DIN |
| Surface | 2B, BA, HL, No. 4, Mirror etc. |
| Finish | Cold rolled, Hot rolled |
| Thickness | 0.15 mm to 3.50 mm |
| Width | 250mm to 750 mm (Mill Edge) 5.0mm to 750 mm (Slit Edge) |
| Grade | Fe | Cr | Ni | Mo | Mn | Nb | Si | Ti | Ta | C | P | S |
| SS 436 | 81.3 | 16 | – | 1 | 1 | 0.5 | – | – | 0.5 | 0.12 | 0.040 | 0.030 |
| SS 436L | 80.49 | 17.3 | 0.3 | 1 | 0.3 | – | 0.3 | 0.3 | – | 0.01 | – | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness |
| 0.28 lbs/in3 7.74 g/cm3 | 2600 – 2750 ° F (1427 – 1510 °C) | 77 KSI min (531 MPa min) | 53 KSI min (365 MPa min) | 40 % | Rb 89 max |
| 0.28 lbs/in3 7.74 g/cm3 | 2600 – 2750 ° F (1427 – 1510 °C) | 441-517 MPa 64000-75000 psi (Metric) | 276-345 MPa 40000-50000 psi (Imperial) | 28-35% | 74-85 |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 436 | 1.4536 | S43600 | SUS 436 |
| SS 436L | – | – | SUS 436L |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 436 angle provides excellent corrosion resistance, especially in high chloride environments, is ideal for offshore industrial applications and provides excellent resistance to scaling and oxidation at high temperatures. The addition of columbium increases weldability and reduces grain growth, thus prolonging durability. Its high strength and durability make it suitable for construction applications, while its attractive finish complements architectural applications. Corner’s exceptional machinability and form capabilities simplify manufacturing processes, reducing costs. It is also highly resistant to stress corrosion cracking, providing long-term reliability in harsh environments.
436 Stainless Steel Angles find their applications in automotive exhaust systems, catalytic converter supports, and heat shields owing to their greater resistance to corrosion and heat. In construction, they are suited for building framing, architectural trim, and indoor/outdoor support brackets, especially where they will be exposed to humidity or mild chemicals. They are used in commercial kitchen equipment, appliance production, and ventilation systems. Their ease of manufacturing, along with good thermal and corrosion resistance, makes SS 436 angles a cost-effective and practical option for industrial use as well as decorative needs.
