Varun Sheets and Plates, one of the leading stainless steel manufacturers and suppliers in Dubai, UAE, provides premium **Stainless Steel 317 Angles** for their exceptional corrosion resistance and strength when used under severe industrial conditions. The angles are specifically designed for structural uses that are subjected to corrosive chemicals and chloride-bearing atmospheres. Made with accuracy and as per international standards, Varun Sheets and Plates supplies Stainless Steel 317 Angles to petrochemical, pulp and paper, chemical processing, and marine industries. With high adherence to quality and reliability, the company provides services to customers in the UAE and worldwide with timely and consistent delivery of products.
**Stainless Steel 317 Angle** is a high-alloy austenitic stainless steel with an approximate composition of 18–20% chromium, 11–15% nickel, and 3–4% molybdenum. The composition gives it enhanced resistance to pitting, crevice corrosion, and chemical attack in acid situations. It has a tensile strength of about 515 MPa, yield strength of 205 MPa, and elongation of about 35%. Stainless Steel 317 also has good formability and weldability. In contrast to 317L, this grade contains slightly more carbon, which increases its strength without sacrificing corrosion resistance in high-temperature and corrosive service.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 317 Angle | : | 5mm to 9mm |
| SS 317 Channel | : | 40mm*20mm~300mm*300mm |
| SS 317 Beam | : | 3″ thru 12.31″ |
| SS 317 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | – |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 317 angle provides excellent corrosion resistance, especially in chloride and acidic environments, making it ideal for extreme conditions and extremely durable, retaining its strength and its integrity at elevated temperatures. The alloy is resistant to pitting and crevice corrosion, increasing its longevity in harsh applications. Stainless steel 317 is easily manufactured and welded, providing versatility for a variety of architectural and industrial applications. Its excellent performance in pharmaceutical, food processing and marine environments makes it reliable for applications requiring high resistance loss.
