Varun Sheets and Plates is a leading manufacturer and supplier of high-quality metal products in Dubai, UAE. At Varun Sheets and Plates, we specialize in a wide range of materials and are renowned for providing premium-grade sheets and plates that cater to various industries. Our Titanium Grade 2 Sheets and Plates are particularly sought for their exceptional corrosion resistance, high strength, and outstanding weldability. Ideal for demanding aerospace, medical, and industrial applications, we ensure reliable, precise, and durable solutions to meet our client’s needs.
Titanium Grade 2 (Ti Gr 2) is a commercially pure titanium alloy composed primarily of titanium (99%) with trace amounts of iron, oxygen, and carbon. This composition ensures excellent corrosion resistance, particularly in seawater and chemical environments. Mechanical properties include a tensile strength of 345 MPa, yield strength of 275 MPa, and elongation of 20%. It has a high strength-to-weight ratio, excellent weldability, and formability, making it suitable for aerospace, marine, and medical applications, where lightweight and durability are essential.
| Specifications | ASTM B265/ ASME SB265 |
|---|---|
| Size | 1000 x 2000 milimeter, 1220 x 2440 milimeter, 1500 x 3000 milimeter, 2000 x 2000 milimeter, 2000 x 4000 milimeter |
| Thickness | 0.1 to 12 milimeter |
| Form | Plates, Sheet, Slatting Coils, Coils, Foils, Plain Sheet, Shim Sheet, Strip, Rolls, Perforated Coils, Flats, Blank , Ring |
| Finish | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade 2 Sheet & Plate | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 2 Sheet & Plate | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 sheets and plates offer excellent corrosion resistance, particularly in marine and chemical environments, making them ideal for aerospace, chemical processing, and marine industries. They are lightweight yet exceptionally strong, providing a high strength-to-weight ratio. Known for their biocompatibility, they are widely used in medical applications. Titanium Grade 2 also has good weldability, formability, and resistance to high temperatures, making it versatile for various applications. Additionally, it exhibits low thermal expansion, enhancing stability in challenging environments.
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in ) |
| .125 | 3.18 |
| .134 | 3.40 |
| .156 | 3.96 |
| .187 | 4.75 |
| .250 | 6.35 |
| .312 | 7.92 |
| .375 | 9.53 |
| .500 | 12.7 |
| .600 | 15.9 |
| .750 | 19.1 |
| .875 | 22.2 |
| 1 | 25.4 |
| 1.125 | 28.6 |
| 1.250 | 31.8 |
| 1.500 | 38.1 |
| 1.750 | 44.5 |
| 2 | 50.8 |
| 2.500 | 63.5 |
| 3 | 76.2 |
Titanium Grade 2 sheets and plates are widely used in industries requiring high corrosion resistance, strength, and lightweight materials. Common applications include chemical processing, aerospace, marine, and medical sectors. In chemical processing, they are used for equipment like heat exchangers and piping systems. In aerospace, titanium sheets and plates are used for aircraft components due to their high strength-to-weight ratio. Additionally, they are utilized for implants and prosthetics in medical applications due to their biocompatibility and resistance to bodily fluids. Their excellent weldability makes them versatile for various industrial applications.
