Varun Sheets and Plates is a well-respected manufacturer and supplier of Stainless Steel 316 Circles based in Dubai, UAE. We provide corrosion-resistant and durable circular components that cater to a variety of industrial sectors. Crafted from high-quality SS 316, our circles are designed to withstand pitting, crevice corrosion, and tough environments, thanks to their molybdenum content. Renowned for our precision manufacturing and rigorous quality control, our 316 circles find applications in fabrication, construction, and chemical processing. With outstanding machinability and formability, Varun Sheets and Plates offers tailored stainless steel circles that comply with both domestic and international standards for critical operations.
The Stainless Steel 316 Circle is composed of 16–18% Chromium, 10–14% Nickel, and 2–3% Molybdenum, along with low Carbon content to enhance weldability and corrosion resistance. This alloy boasts a tensile strength of about 515–750 MPa, a yield strength of around 205 MPa, and an elongation of nearly 40%. In its annealed state, these circles are non-magnetic, provide excellent strength at high temperatures, and show improved resistance to chlorides and other aggressive chemicals, making them perfect for long-term structural applications.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Cnc Finish, Polished Unique, Hot Rolled Circle.. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Grades | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 316 circle offers a number of advantages, including excellent corrosion resistance, especially against chloride and salt water, making it ideal for marine, chemical and high-arm environmental Snakes high tensile strength, durability and the ability to withstand extreme temperatures to ensure long-term performance . Its excellent weldability and formability make it easy to manufacture in a variety of shapes. SS 316 is non-reactive, ensuring hygiene and safety in industries such as food processing and pharmaceuticals. Additionally, it resists pitting, crack corrosion and oxidation, resulting in lower maintenance costs and longer durability under extreme conditions.
You’ll often find Stainless Steel 316 Circles in chemical processing plants, food and beverage equipment, marine and coastal components, architectural structures, and pharmaceutical machinery. Their resistance to saltwater and corrosive substances makes them ideal for heat exchangers, flanges, tank supports, and welded pipe systems. Additionally, SS 316 circles are a popular choice for fabrication projects that require circular blanks or discs for valves, gaskets, or pressure-sensitive applications, thanks to their strength, hygiene, and easy maintenance features.
