Varun Sheets and Plates is a reputable manufacturer and supplier of Hastelloy B2 Sheets and Plates, proudly based in Dubai, UAE. We’re recognized for providing high-performance, corrosion-resistant materials that cater to a variety of industries needing reliable solutions in harsh chemical environments. Our Hastelloy B2 sheets and plates are crafted using cutting-edge techniques and rigorous quality control measures to guarantee consistent strength, durability, and resistance to corrosion. With a solid presence in the region, Varun stands out as a dependable source for top-notch nickel alloy products throughout the Middle East and beyond.
Hastelloy B2 Sheets and Plates mainly consist of nickel (around 69%) and molybdenum (28–30%), along with trace amounts of iron, cobalt, and other elements. This alloy is specifically engineered to withstand hydrochloric acid and other highly reducing chemicals. It boasts remarkable resistance to pitting, stress corrosion cracking, and knife-line attack. In terms of mechanical properties, it offers a tensile strength of about 760 MPa, a yield strength of roughly 300 MPa, and good ductility, making it perfect for forming and welding without sacrificing its corrosion-resistant qualities.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | ASME SB333, ASTM B333 UNS N10665, ASTM B333 UNS N010675, AMS, MSRR, BS |
| Length | 0-12mm or as required |
| Specification of ASTM B333 Alloy B2 Plate | ASTM B333 UNS N10665, ASME SB333, MSRR, BS, AMS 4544 sheet |
| Alloy B2 Plate Width | 0-2500mm or as required |
| UNS N10665 Plate Thickness | 0.3 to 1200 mm or as required |
| Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B333 Alloy B2 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Alloy B2 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.02 max | 26 – 30 | 1.00 max | 0.1 max | 2.0 max | 0.04 max | 0.03 max | 1.0 max | 1.0 max |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy B2 | 9.2 g/cm3 | 1370 °C (2500 °F) | Psi – 51000 , MPa – 350 | Psi – 1,10,000 , MPa – 760 | 40 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy B2 | N10665 | 2.4617 | – | – | – | – | – |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B2 sheets and plates offer exceptional advantages particularly in highly corrosive environments. Known for their superior resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals, they are ideal for chemical processing, storage, and handling systems. Their high strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking ensure long-lasting performance. Additionally, Hastelloy B2 provides outstanding weldability and formability making it easy to fabricate for complex applications. Its ability to maintain structural integrity under extreme conditions reduces maintenance and downtime, enhancing operational efficiency in industries such as pharmaceuticals, chemical and petrochemical.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Hastelloy B2 Sheets and Plates find extensive use in chemical processing, pharmaceuticals, power generation, and waste treatment sectors. Typical applications include pressure vessels, reactors, evaporators, heat exchangers, and piping systems. These sheets and plates are particularly well-suited for components that face highly acidic and reducing environments, especially where resistance to hydrogen chloride gas, sulfuric, acetic, and phosphoric acids is crucial. Their dependable performance and structural integrity make Hastelloy B2 the go-to material for challenging industrial applications that demand long-lasting corrosion protection.
