Varun Sheets and Plates stands out as a top-notch manufacturer and supplier of high-quality Hastelloy B3 Sheets and Plates, proudly based in Dubai, UAE. Known for our commitment to precision-engineered and corrosion-resistant materials, we cater to a diverse array of industries that rely on dependable nickel alloy solutions. Our Hastelloy B3 sheets and plates are crafted using cutting-edge manufacturing techniques, ensuring they boast dimensional accuracy, superior quality, and exceptional performance even in the most corrosive environments. Varun has earned a reputation as a trusted supplier throughout the Middle East, providing reliable and durable metal solutions tailored for critical applications.
Hastelloy B3 Sheets and Plates are primarily made up of nickel (about 65%) and molybdenum (28.5–30.5%), along with small amounts of iron, cobalt, chromium, and other elements. This unique composition grants them remarkable resistance to hydrochloric acid across all concentrations and temperatures, while also protecting against pitting, stress corrosion cracking, and knife-line attack. On the mechanical side, Hastelloy B3 showcases a tensile strength of around 760 MPa, good ductility, and excellent thermal stability, maintaining its properties even after welding or forming.
Specifications :ASTM B333 / ASME SB333
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 4000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | Al | Co | Ni | Cr | Fe | Mo | Ti |
| Hastelloy B3 | 0.01 max | 3.0 max | 0.10 max | 0.50 max | 3.0 max | 65.0 min | 1.5 | 1.5 | 28.5 | 0.2 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 9.22 g/cm3 | 1418°C (2585°F) | 1000 – 2000 N/mm² , 145 – 290 ksi | 62 – 183 Ksi, 425 – 1260 MPa | 57 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Hastelloy B3 | 2.4600 | N10675 |
Stocked Sizes | |
|---|---|
Size (in inches) | Size (in mm) |
.125″ | 3.18mm |
.134″ | 3.40mm |
.156″ | 3.96mm |
.187″ | 4.75mm |
.250″ | 6.35mm |
.312″ | 7.92mm |
.375″ | 9.53mm |
.500″ | 12.7mm |
.600″ | 15.9mm |
.750″ | 19.1mm |
.875″ | 22.2mm |
1″ | 25.4mm |
1.125″ | 28.6mm |
1.250″ | 31.8mm |
1.500″ | 38.1mm |
1.750″ | 44.5mm |
2″ | 50.8mm |
2.500″ | 63.5mm |
3″ | 76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B3 sheets and plates offer exceptional advantages, especially in harsh, corrosive environments. They provide outstanding resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals ensuring reliability in chemical processing and waste treatment applications. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking they ensure long-term durability. The materials high strength and ease of fabrication further enhance its suitability for complex designs and welding. Hastelloy B3 superior performance in reducing conditions, combined with its ability to maintain structural integrity under extreme conditions, makes it a preferred choice for critical industrial applications.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
These Hastelloy B3 Sheets and Plates find their way into various sectors, including chemical processing, pharmaceutical manufacturing, aerospace, and marine applications. Common uses include reactor vessels, heat exchangers, evaporators, and chemical storage tanks. They are particularly well-suited for equipment that faces highly reducing environments, especially where hydrochloric acid or other aggressive media are involved. Thanks to their outstanding formability, weldability, and corrosion resistance, they are the go-to choice for crafting long-lasting and reliable components in some of the toughest industrial conditions.
