Varun Sheets and Plates is a reliable Nickel Alloy 200 Foils manufacturer and supplier in Dubai, UAE, providing high-quality foils for application in highly corrosive and high-temperature conditions. Nickel 200 is a commercially pure wrought nickel alloy with a minimum of 99.6% containing outstanding mechanical properties along with superior resistance to a broad spectrum of corrosive media. Varun Sheets and Plates offers Nickel 200 Foils in different thicknesses and widths, carefully produced to global standards, providing high performance in chemical processing, electronics, aerospace, and marine applications.
Nickel Alloy 200 is composed of a minimum of 99.6% pure nickel, with a small percentage of iron, manganese, carbon, and silicon. The alloy has superior resistance to neutral and alkaline salts, caustic alkalis, and dry gases at room temperature. It has satisfactory mechanical properties, such as tensile strength of around 55,000 psi and good ductility and thermal conductivity. Nickel 200 retains its strength and stability from cryogenic temperatures to 600°F (315°C), and it is very resistant to corrosion, particularly in reducing environments. The alloy is also non-magnetic and readily fabricated, welded, and formed.
Specifications : ASTM B168 / ASME SB168
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm
Form : Foils, Rolls
Thickness : 0.1mm to 12 mm Thk
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 foils offer excellent corrosion resistance, especially in alkalis, acids, and various chemicals, making them ideal for harsh environments. Known for their high thermal and electrical conductivity, these foils are widely used in applications like electrical components and heat exchangers. They possess outstanding mechanical properties, including strength and flexibility, allowing easy fabrication. Additionally, Nickel Alloy 200 foils exhibit good weldability and formability, making them suitable for various industrial applications, including aerospace, chemical processing, and marine environments. Their stability at elevated temperatures further enhances their reliability.
Nickel Alloy 200 Foils are extensively applied in industries where high purity, corrosion resistance, and heat conductivity are essential. In chemical and food processing, they are utilized for caustic solution equipment such as heat exchangers, vessels, and piping. In electronics and electrical industries, Nickel 200 Foils are employed in battery components, shielding materials, and precision resistors because of their conductivity and formability. They find application in aerospace and marine industries in the form of corrosion-resistant gaskets and sealing. These foils are further suitable for producing components that need resistance to high temperatures and chemically aggressive environments.
