Varun Sheets and Plates, a well-known UAE stainless steel manufacturer and supplier in Dubai, provides high-grade Stainless Steel 321 Angles specifically designed for high-temperature and corrosion-resistant applications. Having excellent structural strength, weldability, and toughness, these angles are extensively used in thermal processing, chemical, and aerospace sectors. With a rigid emphasis on product uniformity, punctual delivery, and customer satisfaction, Varun Sheets and Plates guarantees that its Stainless Steel 321 Angles are up to international standards and perform consistently well in harsh conditions in industrial and structural applications across the UAE and internationally.
Stainless Steel 321 Angle is a titanium-stabilized austenitic stainless steel with about 17–19% chromium, 9–12% nickel, and trace amounts of titanium (at least five times the level of carbon). This prevents precipitation of carbides in welding and high-temperature heating. It provides tensile strength of about 515 MPa, yield strength of 205 MPa, and elongation of 35%. The alloy exhibits excellent resistance to intergranular corrosion, good creep strength, and high-temperature oxidation resistance, and is therefore ideal for long-term service in environments above 427°C.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 321 angle provides excellent corrosion resistance, especially against high temperatures and acidic environments, making it ideal for applications in industries such as aerospace, chemical processing and automotive It has weldability excellent properties, formability and strength, ensuring durability and structural integrity in critical applications . The addition of titanium increases the stability of the alloy, prevents carbide precipitation during welding, increases its performance in high temperature environments This stainless steel also provides excellent resistance to scaling and oxidation , ensures long-term reliability and minimal maintenance under extreme conditions Its versatile nature in construction engineering . of applications Makes it suitable for a wide range of applications.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
