Varun Sheets and Plates, a reputable Dubai, UAE manufacturer and supplier, provides high-performance Stainless Steel 310H Angles for high-temperature applications and challenging environments. Renowned for their superior strength, hardness, and oxidation resistance, these angles are suitable for heavy-duty industrial applications. Varun Sheets and Plates provides accuracy in manufacturing as well as strict compliance with international quality standards and delivers Stainless Steel 310H Angles to industries like power generation, petrochemicals, thermal processing, and heat treatment. With the reliability factor and quick service, the company is continuing to perform effectively for clients in the UAE as well as overseas markets.
Stainless Steel 310H Angle is a high-carbon variant of SS 310 with primary composition of chromium (24–26%) and nickel (19–22%) and an increased content of carbon (0.04–0.10%) to provide high-temperature strength and creep resistance. The tensile strength is about 515 MPa, yield strength is 205 MPa, and elongation is 40%. The alloy provides excellent resistance to oxidation until 1040°C in continuous service and good toughness even at cryogenic temperatures. Stainless Steel 310H Angle is corrosion- and scaling-resistant, which makes it compatible for use in pressure vessels and high-temperature structural applications.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 310H Angle | : | 5mm to 9mm |
| SS 310H Channel | : | 40mm*20mm~300mm*300mm |
| SS 310H Beam | : | 3″ thru 12.31″ |
| SS 310H Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 310H | 0.04 – 0.10 | 2 max | 1.0 max | 0.045 max | 0.030 max | 24 – 26 | – | 19 – 21 | 53.885 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310H | S31009 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 310H angle provides excellent resistance to high temperature oxidation and corrosion, making it ideal for use in furnaces, heat exchangers and exhaust systems Its high chromium and nickel content provides excellent strength and durability exist longer at higher temperatures. The alloy has excellent weldability and formability, making it suitable for structural applications. In addition, the stainless steel 310H surface retains its mechanical properties in areas of thermal cycling and chemical exposure These properties ensure durability and reliability in applications such as petrochemical, aerospace, and in power generation.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
