Varun Sheets and Plates, a trusted stainless steel supplier and manufacturer in Dubai, UAE, provides high-quality Stainless Steel 301 Angles used for applications demanding superior strength, good resistance to corrosion, and improved formability. The angles are suitable for structural frameworks, mechanical parts, and architectural fabrications. Through precision engineering and following international standards of quality, Varun Sheets and Plates is committed to making its SS 301 Angles available for the requirements of customers in various industries in the UAE as well as internationally.
Stainless Steel 301 Angle is an austenitic chromium-nickel stainless steel that contains about 16–18% chromium and 6–8% nickel. It is characterized by very high tensile strength in the range of 620–950 MPa depending on temper and a yield strength of about 275 MPa. The alloy has a good corrosion resistance in mildly corrosive environments and has excellent mechanical properties, especially after cold working, which greatly enhances its hardness and strength.
| Specifications | ASTM A276 / ASME SA276 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Angles Size | 20mm to 200mm |
| Angle Thickness | 3mm to 12mm |
| Angles Length | Upto 6 Meters Long |
| Angles Types | Equal, Unequal, L Angle, Equal Leg Angle, Unequal Leg Angle, Hot Rolled Angle, Angle |
| ELEMENT | C | Mn | P | S | Si | Cr | Ni | N |
|---|---|---|---|---|---|---|---|---|
| SS 301 | 0.150 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.10 |
| SS 301L | 0.03 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.02 |
| Grade | Tensile Strength ksi (min.) | Yield Strength 0.2% ksi (min.) | Elongation -% in 50 mm (min.) |
|---|---|---|---|
| SS 301 | 185 | 140 | 9 |
| SS 301L | 550 | 220 | 45 |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
|---|---|---|---|
| SS 301 | 1.4310 | S30100 | SUS 301 |
| SS 301L | – | S30103 | SUS 301L |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 301 Angle provides excellent corrosion resistance, especially in bright environments, making it suitable for outdoor marine applications. It has consistency and can easily be shaped. The alloy provides high tensile strength and moderate hardness, ensuring durability and structural integrity. It also exhibits excellent fatigue resistance and easily cracks under stress, making it ideal for use in the industrial and construction industries In addition to stainless steel 301 Angle retains its properties in environments is extremely hot, providing versatility and reliability.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 301 Angles are used extensively where there is a need for high strength-to-weight ratio and wear and fatigue resistance. Some of such applications include rail car components, truck trailer parts, aircraft structures, architectural trims, and industrial equipment. SS 301 is also widely employed in fabricating storage systems, automotive components, and appliance components. The alloy’s durability for moderate corrosion with superior ductility and formability qualifications makes the alloy appropriate for forming and welding processes in most fabrication settings. SS 301 Angles provide a cost-effective, versatile solution for structural and decorative uses requiring durability and aesthetics.
