Varun Sheets and Plates, a well-known stainless steel supplier and manufacturer in Dubai, UAE, offers superior **Stainless Steel 304H Angles**, designed for pressure and temperature applications. Due to higher carbon content, these angles offer improved strength and are best suited for use in structural applications in petrochemicals, power generation, and thermal processing. Varun Sheets and Plates supplies SS 304H Angles as per international standards with durability, consistent quality, and performance. The firm is known throughout the UAE and international markets for its reliable supply chain and adherence to excellence.
**Stainless Steel 304H Angle** is a high-carbon version of 304 stainless steel, with roughly 18–20% chromium, 8–11% nickel, and 0.04–0.10% carbon content. This added carbon improves high-temperature strength and creep resistance, suited for high temperature service. The material provides a tensile strength of approximately 585 MPa, yield strength of 290 MPa, and elongation of approximately 40%. SS 304H has good corrosion resistance, weldability, and mechanical properties in oxidizing and mildly reducing environments.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 304 Angle provides excellent corrosion resistance, making it ideal for harsh environments including coastal areas and industrial conditions Its high strength-to-weight ratio ensures durability and structure of the integrity without excessive quantity. This alloy is easy to fabricate, weld and machine, making it versatile. The material also offers excellent resistance to oxidation and staining, making it suitable for both indoor and outdoor use. Furthermore, the stainless steel 304 Angle is resistant to many chemicals and has high purity, making it attractive to the food and pharmaceutical industries.
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Our team is ready to assist you. Contact us for any queries or personalized solutions.
