Varun Sheets and Plates, being a reliable stainless steel manufacturer and supplier in Dubai, UAE, provides high-performance Stainless Steel 304H Angles to be used in applications where there is a need for higher strength and heat resistance. Having more carbon content than the regular 304, these angles are used in high-temperature and structural applications in power plants, refineries, and heat exchangers. Reputed for providing quality products that satisfy international standards, Varun Sheets and Plates provides accurate manufacturing, timely delivery, and reliable service to customers in the UAE and international markets
Stainless Steel 304H Angle is a high-carbon version of SS 304 that has about 18–20% chromium, 8–11% nickel, and 0.04–0.10% carbon. The higher content of carbon enhances tensile and creep strength at high temperature, and it is used for long-term exposure in higher temperatures. It gives tensile strength of about 585 MPa, yield strength of 290 MPa, and excellent endurance and oxidation resistance in thermal stress. SS 304H also has good weldability and corrosion resistance in various environments.
| Specifications | ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790 |
|---|---|
| Dimensions | ASTM, ASME and API |
| 304 Pipes & Tubes | 1/2″ NB – 16″ NB |
| ERW 304 Pipes & Tubes | 1/2″ NB – 24″ NB |
| EFW 304 Pipes & Tubes | 6″ NB – 100″ NB |
| Size | 1/8″NB TO 30″NB IN |
| Specialized in | Large Diameter Size |
| Schedule | SCH5, SCH10, SCH20, SCH30, SCH40, Std, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Lengtd. |
| End | Plain End, Beveled End, Treaded |
| C | MN | SI | P | S | CR | NI | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304H | min: 18.0 max:20.0 | min: 8.0 max: 10.5 | min: 0.04 max:0.10 | 0.75 max | 2.0 max | 0.045 max | 0.03 max | 0.10 max |
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 304H | 1.4948 | S30409 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The Stainless Steel 304H Angle offers several advantages, including excellent corrosion resistance, especially in high-temperature environments, making it suitable for applications such as boilers, pressure vessels and more It has excellent weldability and formability, which allows for easy fabrication. The high carbon content of the 304H provides high strength and stability, especially at elevated temperatures. It also provides excellent resistance to oxidation and scaling. This compound is very versatile and can be used in the chemical, petrochemical and food processing industries. Its long-term performance and low cost make it popular in construction applications.
| SS 304 | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 | Thermal Conductivity (BTU/h ft. °F) | Electrical Resistivity (in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/ °F x 10-6 | Specific Heat (BTU/lb/ °F) | Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 304H | ||||||
| Denstiy lbm/in3 | Coefficient of Thermal Expansion (min/in)-°F | Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
Stainless Steel 304H Angles find extensive application in high-heat resistant applications like boilers, heat exchangers, pressure vessels, superheaters, and furnace parts. The toughness and heat resistance of Stainless Steel 304H Angles qualify them to find application in power generation, petrochemical processing, and refinery operations. They are also used in structural frames and piping systems where corrosion resistance along with long-term performance at elevated temperatures is needed. SS 304H Angles provide a great combination of strength, durability, and heat resistance, so these are the good choice in extreme industrial conditions.
