Varun Sheets and Plates is a leading manufacturer and supplier of Stainless Steel 305 Angle in Dubai, UAE, and is renowned for offering premium-quality stainless steel products with superior formability and corrosion resistance. Their SS 305 angles are precision-engineered and meet international standards, making them perfect for industries requiring non-magnetic properties and high-performance fabrication. Operating across a broad spectrum of industries such as electrical, food processing, construction, and medical, Varun Sheets and Plates believes in quality, timely delivery, and customer satisfaction in the UAE and overseas.
Stainless Steel 305 Angle is an austenitic alloy of iron, 17–19% chromium, 10.5–13% nickel, and 0.12% max carbon. The high nickel content enhances its resistance to corrosion as well as its deep drawing and forming properties. SS 305 has a tensile strength of approximately 520 MPa and a yield strength of 205 MPa. It does not become magnetic even upon cold working and possesses high ductility, weldability, and surface finish, making it ideal for intricate fabrication and forming.
| Specifications | ASTM A240 / ASME SA240 | ||||||
| Thickness | 0.5mm-100mm | ||||||
| Outer diameter | 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Round tube Square tube Rectangular tube etc. | ||||||
| Grade | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness | |
| Rockwell B (HRB) | Brinell (HB) | ||||
| 305 | 480 | 177 | 40 | 90 | 187 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 305 | Min. | / | / | / | / | / | 17 | / | 10.5 | / |
| Max. | 0.12 | 2 | 0.75 | 0.045 | 0.03 | 19 | / | 13 | / |
| ASTM | UNS No. | ISO | Euronorm | China GB | Japanese JIS | ||
| No. | Name | ||||||
| 305 | S30500 | X6CrNi 18-12 | 1.4303 | X6CrNi 18-12 | 10Cr18Ni12 | SUS 305 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 305 angle offers many advantages, including excellent corrosion resistance, excellent strength and durability, especially in areas prone to moisture and dampness, and makes it ideal for construction applications. The alloy’s corrosion and stain resistance makes it durable, and requires little maintenance. Stainless steel 305 also exhibits excellent formability, making it easy to fabricate and weld. In addition, it stays in shape for a long time due to its non-reactive surface. This makes it suitable for industries such as construction, automotive and marine, where high-performance materials are important.
Stainless Steel 305 Angles find broad usage in applications that need high formability and moderate corrosion resistance. These are used in equipment for foods and liquids, kitchen appliances, trim items, medical equipment, and electrical enclosures. Their non-magnetic properties make them particularly ideal for sensitive electronic and instrumentation applications. SS 305 angles are also used in structural parts and custom fabrications where deep drawing and intricate forming are required. Their strength, flexibility, and resistance to mild corrosive conditions make them a material of choice for hygienic, aesthetic, and functional purposes.
