Varun Sheets and Plates is a renowned stainless steel producer and provider in Dubai, UAE, providing long-lasting yet affordable Stainless Steel 201 Angles for diverse structural and decorative purposes. With good strength, formability, and corrosion resistance, these angles are extensively applied in construction, architectural structures, vehicles, and industrial manufacturing. Varun Sheets and Plates maintains top-level production standards, assured supply, and customer satisfaction, which makes them a sought-after source for Stainless Steel 201 Angles throughout the UAE and the global markets.
Stainless Steel 201 Angle is a chromium-nickel-manganese austenitic stainless steel with a composition of about 16–18% chromium, 3.5–5.5% nickel, and 5.5–7.5% manganese. It has a tensile strength of about 520–690 MPa and a yield strength of about 275 MPa. The alloy has good hardness, moderate corrosion resistance, and good formability, as a result of which it is widely used as a substitute for 304 stainless steel in less corrosive applications. Its lower nickel content also makes it an economical choice for non-critical applications.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 201 Angle provides excellent corrosion resistance, making it ideal for use in light to medium environments. Lightweight yet durable, it provides high stability and system integrity. Its excellent weldability and formability make it easy to manufacture in a variety of configurations. It has excellent oxidation resistance and works well at high temperatures. Affordable compared to other stainless steel grades, it maintains an attractive look with minimal maintenance. Its versatility allows it to be used in construction, automotive, and industrial applications, providing longevity and value.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
Stainless Steel 201 Angles are commonly applied in structural supports, machinery of industry, domestic appliances, trailers, railways, and appearance trims. These angles find applications where high strength and looks are necessary but exposure to highly corrosive substances is minimal. SS 201 Angles are also applied in interior designing, frames, brackets, and equipment housings due to their attractive finish and formability. Though not advisable for saltwater or heavily corrosive chemical exposure, SS 201 Angles provide great value for general-purpose manufacturing and construction applications.
