Varun Sheets and Plates is your go-to manufacturer and supplier of Stainless Steel 317 Sheets and Plates right here in Dubai, UAE. We pride ourselves on delivering top-notch products that are built to endure harsh, corrosive, and high-temperature environments. SS 317 is a special type of austenitic stainless steel that contains molybdenum, giving it outstanding resistance to chemical attacks, particularly from sulfurous, acetic, and formic acids. With a strong focus on precision and customer satisfaction, Varun Sheets and Plates provides Stainless Steel 317 sheets and plates that cater to demanding industries like petrochemicals, marine engineering, and chemical processing, all while meeting international standards and offering customized dimensions.
Our Stainless Steel 317 Sheets and Plates are made up of 18–20% Chromium, 11–15% Nickel, 3–4% Molybdenum, and a maximum of 0.08% Carbon. These components work together to provide remarkable resistance to pitting and crevice corrosion. In terms of mechanical properties, you can expect a tensile strength ranging from 515–760 MPa, a yield strength of 205 MPa, and an elongation of about 35–40%. SS 317 is non-magnetic when annealed and maintains its structural stability and mechanical integrity even in high temperatures and aggressive chemical settings.
| 317 Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 317 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 317 Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 317 Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 317 Stainless Steel Sheet 3.0–10.0 mm |
| 317 SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 317 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 317 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 317 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 317 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 317 SS Strips EN 10088 SA -240-304 / 317 Strips |
| Finish of SS 317 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | – |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 317 sheets and plates provide exceptional corrosion resistance, especially in acidic environments, making them ideal for chemical, petrochemical and pharmaceutical applications Due to their high chromium and molybdenum content, they provide excellent durability and strength at higher temperatures. These materials are highly resistant to pitting, crevice corrosion, and stress corrosion cracking. Additionally, stainless steel 317 is easy to weld, fabricate and maintain, providing long service life. Its aesthetic appeal and oxidation resistance further enhance its suitability for building and construction applications, and provide functional and visual advantages
You’ll find Stainless Steel 317 Sheets and Plates being widely utilized in chemical and petrochemical plants, pulp and paper processing, food and beverage equipment, and marine environments. Their superior corrosion resistance and ability to thrive in acidic and chloride-rich conditions make them perfect for heat exchangers, tanks, pressure vessels, evaporators, and piping systems. Plus, the alloy’s strength and durability at high temperatures make it a top choice for refinery units and other applications that demand a long service life with minimal maintenance.
