Varun Sheets and Plates is a well-respected manufacturer and supplier of top-notch Stainless Steel 13-8 PH Sheets and Plates based in Dubai, UAE. We cater to high-performance sectors such as aerospace, defense, and petrochemicals. Renowned for its remarkable strength, toughness, and resistance to corrosion, 13-8 PH is a precipitation-hardened stainless steel that’s perfect for critical structural components. Our sheets and plates are crafted to meet rigorous international standards and come in a range of thicknesses and tempers. At Varun, we pride ourselves on precision engineering, dependable supply, and a customer-centric approach throughout the Middle East and global industrial markets.
The Stainless Steel 13-8 PH Sheets and Plates consist of about 13% chromium, 8% nickel, along with some aluminum and molybdenum. This alloy boasts impressive tensile strength (up to 1400 MPa after aging), excellent yield strength, and good ductility. It maintains its mechanical properties even in corrosive and stress-laden environments. The 13-8 PH is hardened through a straightforward aging process, providing solid toughness in both longitudinal and transverse directions, making it ideal for high-strength applications where dimensional stability and resistance to stress corrosion cracking are crucial.
| Specifications | 1.4534.9 | UNS S13800 | AMS 5629 |
| Item: | Stainless Steel Plates (Hot rolled, cold rolled) |
| Standard: | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface: | The surface and finish of Stainless-Steel Plates: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Width: | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length: | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness: | 0.3~10.0mm |
| Form: | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| End: | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Cr 12.25 – 13.23% | Ni 7.50 – 8.50% | Mo 2.00 – 2.50% | Al 0.90 – 1.35% | N 0.010% | |||||
| Mn 0.10% | Si 0.10% | C 0.05% | P 0.010% | S 0.008% |
| Tensile (UTS)N/mm² | 0.2% YieldN/mm² | Elongation(50.8mm) %) | HardnessHRc | Reductionof Area |
| 1965 | 1896 | 2 | 57 | 10 |
| Alloy | UNS Number | WERKSTOFF NR. |
| 13-8 PH | UNS S13800 | 1.4534 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 13-8 PH sheets and plates offer many benefits, including high strength, good corrosion resistance and outstanding hardness. Their ability to resist stress corrosion cracking makes them ideal for complex applications in the aerospace, marine, and nuclear industries. These sheets and plates are very durable, perform well in high-pressure and extreme-temperature environments, and maintain consistent mechanical properties They can be easily welded and machined, providing a variety of options a they are used for many purposes. By serving long life and reliability they are a cost-effective solution for critical applications that require precision and durability.
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| Stainless Steel 13-8 PH PH 1D – Hot rolled, heat treated, pickled Plate & Sheet | 2.4–12.7 | max. 2032 |
| 2R – Stainless Steel 13-8 PH Cold-rolled, bright-annealed Sheet & Plate | 0.05–1.50 | 3–649 |
| 2H – Stainless Steel 13-8 PH Work hardened Plate & Sheet | 0.05–1.50 | 3–630 |
| 2B – Stainless Steel 13-8 PH Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 0.25–8.0 | max. 2032 |
| 2D – Stainless Steel 13-8 PH Cold rolled, heat treated, pickled Plate & Sheet | 0.4–6.35 | max. 1524 |
| 2E – Stainless Steel 13-8 PH Cold rolled, heat treated, mechanically descaled Sheet & Plate | 0.4–8.0 | max. 2032 |
| 2R – Stainless Steel 13-8 PH Cold rolled, bright annealed Plate & Sheet | 0.25–3.5 | max. 1524 |
| 2H – Stainless Steel 13-8 PH Work hardened Sheet & Plate | 0.4–6.35 | max. 1524 |
| Stainless Steel 13-8 PH Polished, brushed Plate & Sheet | 0.5–4.0 | max. 1524 |
Yes, we offer custom sizes for Stainless Steel 13-8 PH Sheet and Plates to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) |
| 0.282 | 1.72 | 97 | 0.11 | 0.00000589 | 2560 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
These Stainless Steel 13-8 PH Sheets and Plates are extensively utilized in the aerospace industry for structural components, landing gear, and fasteners. You’ll also find them in chemical processing equipment, marine hardware, nuclear plant components, and oil & gas tools. These sheets are perfect for applications that demand high strength-to-weight ratios, corrosion resistance, and reliable performance under dynamic loads. The alloy’s ability to maintain mechanical integrity at elevated temperatures and resist stress corrosion cracking makes it essential for precision-machined parts and safety-critical engineering systems.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
