Varun Sheets and Plates is your go-to manufacturer and supplier of Stainless Steel 316H Sheets and Plates right here in Dubai, UAE. We specialize in high-performance stainless steel solutions that are perfect for those tough high-temperature and pressure environments. Stainless Steel 316H is a high-carbon variant of SS 316, crafted specifically to provide superior strength and creep resistance when the heat is on. With our commitment to precision manufacturing and strict adherence to international standards, our 316H sheets and plates are just what industries like power generation, oil refining, petrochemical processing, and heat exchanger construction need. They ensure structural stability, resist corrosion, and boast a long service life even in the most demanding applications.
Our Stainless Steel 316H Sheets and Plates are made up of 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and a higher Carbon content (0.04–0.10%) compared to standard 316. This extra carbon really boosts high-temperature strength and creep resistance. When it comes to mechanical properties, you can expect a tensile strength of 515–760 MPa, a yield strength around 205 MPa, and an elongation of about 40%. SS 316H is non-magnetic when annealed and offers fantastic corrosion resistance, especially in chloride environments, along with excellent weldability and formability for structural and pressure vessel applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 316H Sheet and Plates offers several key benefits, especially in high-temperature environments. Its high carbon content also increases creep resistance, making it ideal for structural application in the chemical, petrochemical and marine industries. The material boasts excellent corrosion resistance, especially against chloride, pitting and crevice corrosion. It also performs well in extreme temperatures, maintaining its integrity in high temperature conditions. In addition, stainless steel 316H is durable, easy to manufacture, and highly resistant to oxidation, providing long service life with minimal maintenance These properties make it ideal for environmental production difficult to destroy.
You’ll find Stainless Steel 316H Sheets and Plates commonly used in heat exchangers, boilers, pressure vessels, superheaters, and furnace parts because they can handle high temperatures and corrosive conditions with ease. Industries like petrochemical, oil & gas, and power plants rely on 316H for components that face high heat and aggressive chemicals. Its high carbon content guarantees enhanced strength under thermal stress while still maintaining the corrosion resistance that the 316 series is known for. Plus, SS 316H is also a great choice for industrial food processing and marine equipment where heat and corrosion resistance are absolutely crucial.
