Varun Sheets and Plates is a well-respected manufacturer and supplier of Stainless Steel 316 Sheets and Plates based in Dubai, UAE. We pride ourselves on offering top-notch stainless steel products that are specifically designed for environments that demand corrosion resistance and high performance. Stainless Steel 316 is an austenitic stainless steel enriched with molybdenum, renowned for its exceptional resistance to pitting, crevice corrosion, and general oxidation. Our SS 316 sheets and plates are crafted with precision, ensuring they deliver outstanding durability, weldability, and formability. We serve a diverse array of industries, including marine, chemical processing, food production, and pharmaceuticals, providing dependable stainless solutions that are built to last.
The composition of Stainless Steel 316 Sheets and Plates includes 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and a maximum of 0.08% Carbon. The inclusion of molybdenum significantly boosts resistance to chloride environments and chemical corrosion. SS 316 boasts impressive mechanical properties, featuring a tensile strength ranging from 515 to 760 MPa, a yield strength of around 205 MPa, and an elongation of 40%. It remains non-magnetic in its annealed state and showcases excellent toughness, formability, and weldability, making it perfect for demanding operating conditions and high-stress applications in corrosive and humid environments.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 316 sheets and plates have many advantages, including exceptional corrosion resistance, especially in high chloride environments, making them ideal for marine and chemical applications They are extremely durable, . it has good strength, resistance to potholes, crack corrosion, and oxidation . It also provides excellent weldability, formability and toughness at high and low temperatures. Stainless Steel 316 is non-magnetic and resistant to extreme conditions, providing durability and reliability. These properties make it ideal for food processing, pharmaceutical, marine, and other industries.
You’ll find Stainless Steel 316 Sheets and Plates commonly used in marine equipment, chemical storage tanks, heat exchangers, medical devices, and food processing machinery. Their outstanding corrosion resistance makes them particularly suitable for coastal and offshore applications, as well as in the pharmaceutical and sanitary sectors where cleanliness and chemical stability are crucial. Additionally, SS 316 is utilized in architectural features and water treatment systems due to its ability to withstand moisture, acids, and chlorides. Its versatility and durability guarantee long-lasting performance and minimal maintenance, even in challenging service conditions.
