Varun Sheets and Plates stands out as a top-notch manufacturer and supplier of Stainless Steel 253MA Sheets and Plates in Dubai, UAE. They provide cutting-edge material solutions designed for high-temperature and corrosive environments. SS 253MA is an austenitic stainless steel crafted for exceptional oxidation resistance, impressive high-temperature strength, and remarkable structural stability. Varun takes pride in delivering precisely fabricated 253MA sheets and plates that adhere to international quality standards, making them perfect for industries like thermal processing, petrochemicals, and metallurgy. With a strong focus on performance, reliability, and customer satisfaction, Varun ensures their products are built for long-lasting durability, even in the toughest applications.
The composition of Stainless Steel 253MA Sheets and Plates includes about 21% chromium, 11% nickel, 1.7% silicon, along with small amounts of nitrogen and rare earth metals. These elements significantly boost the alloy’s strength and oxidation resistance at high temperatures. SS 253MA boasts a tensile strength ranging from 600 to 800 MPa and a yield strength of around 310 MPa. It retains excellent mechanical properties and creep resistance at temperatures exceeding 1000°C. Additionally, this alloy is recognized for its good weldability, formability, and resistance to thermal fatigue, making it a great choice for applications that demand high structural integrity in extreme heat.
| Grade | 253 MA| UNS S30815 |
| Standard | ASTM A240 / ASME SA240 |
| Thickness | 0.1mm To 100 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Applications | Off-Shore Oil Drilling Companies, Power Generation, Petrochemicals, Gas Processing, Specialty Chemicals, Pharmaceuticals, Pharmaceutical Equipment, Chemical Equipment, Sea Water Equipment, Heat Exchangers, Condensers, Pulp and Paper Industry |
| Grade | C | Mn | Si | S | Ce | Ni | Cr | P |
| 253 MA | 0.05 – 0.10 | 0.80 max | 1.40 – 2 | 0.030 max | 0.03 – 0.08 | 10 – 12 | 20 – 22 | 0.040 max |
| Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.8 g/cm3 | MPa -600 | MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
DIN 1.4835 Sheets and Plates offer outstanding advantages, including exceptional oxidation resistance up to 1150°C, making them ideal for high-temperature applications. Their balanced composition enhances creep resistance and ensures durability under thermal cycling. The addition of silicon and nitrogen improves strength and ductility, while cerium boosts stability in oxidizing environments. These sheets are easy to fabricate and weld, reducing production challenges. With superior corrosion resistance and excellent mechanical properties, they are highly suitable for applications in petrochemical plants, heat exchangers, and furnace components, ensuring reliability and long service life.
| Surface finish | Thickness (in) | Width (in) |
|---|---|---|
| 1 – Stainless Steel 253 MA Hot rolled, heat treated, pickled Plate & Sheet | .1000 – .3750 | max. 72 |
| 2R – Stainless Steel 253 MA Cold-rolled, bright-annealed Sheet & Plate | 0.002–0.06 | 0.118–25.551 |
| 2H – Stainless Steel 253 MA Work hardened Plate & Sheet | 0.002–0.06 | 0.118–24.803 |
| 2B – Stainless Steel 253 MA Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 10–24 | max. 72* |
| 2D – Stainless Steel 253 MA Cold rolled, heat treated, pickled Plate & Sheet | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Deco Rolled-On Mexinox only | 14–28 | max. 48 |
| Stainless Steel 253 MA Polished Plate & Sheet (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
| STANDARD | WERKSTOFF NR. | UNS | SS | EN |
| 253 MA | 1.4835 | S30815 | 2368 | X9CrNiSiNCe21-11-2 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS / COILS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
Stainless Steel 253MA Sheets and Plates are commonly utilized in high-temperature industrial settings, including furnace components, heat exchangers, burner nozzles, and kiln linings. In the petrochemical sector, it’s used in reformer tubes, manifolds, and other structural components that face thermal cycling. The alloy’s outstanding resistance to scaling and deformation makes it ideal for metallurgy, power plants, and thermal process equipment. SS 253MA is also valuable in cement and steel manufacturing, where long-term strength and heat endurance are essential. Its reliable performance under continuous high temperatures ensures minimal maintenance and maximum efficiency.
