Varun Sheets and Plates is a prominent producer and supplier of Stainless Steel 17-7 PH Channel in Dubai, UAE, providing premium stainless steel solutions for applications that require superior strength, corrosion resistance, and fatigue resistance. With a reputation for precision engineering and following international standards, Varun Sheets and Plates provides SS 17-7 PH channels that can be used in aerospace, chemical processing, marine, and high-stress structural use. Through its robust distribution network and customer satisfaction-driven philosophy, the company offers long-lasting and reliable stainless steel products across the UAE and overseas.
Stainless Steel 17-7 PH Channel is a precipitation-hardened stainless steel alloy made up of iron, 16–18% chromium, 6.5–7.75% nickel, 0.75–1.5% aluminum, and low carbon (≤0.09%). It has superior mechanical properties such as tensile strength of up to 1100 MPa and yield strength of up to 960 MPa following heat treatment (Condition CH900). The alloy has high strength with moderate corrosion resistance and superior fatigue and stress corrosion cracking resistance, and it is therefore appropriate for high-load and cyclic applications.
| Standard | ASTM A240 / ASME SA240, ASTM A276 / A182, ASTM A479 – AL-6XN, A286 |
| Width | 1000mm-2000mm |
| Thickness | 1.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coil, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Element | 17-7PH |
| Carbon | 0.09 |
| Chromium | 16.0-18.0 |
| Nickel | 6.5-7.7 |
| Manganese | 1.00 |
| Silicon | 1.00 |
| Aluminum | 0.75-1.50 |
| Phosphorus | 0.040 |
| Sulfur | 0.030 |
| Property | 17-7PH ≤ 0.010 inch thick | 17-7PH > 0.010 inch thick |
| Yield Strength, min. (ksi) | 65 | 55 |
| Tensile Strength, min. (ksi) | 150 | 150 |
| Elongation, min. (%) | – | 20 |
| Hardness, max. (Rb) | – | 92 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless Steel 17-7 PH Channel offers several key advantages, including exceptional strength, corrosion resistance, and excellent fatigue resistance, making it suitable for demanding applications. Its precipitation-hardening capability allows for tailored mechanical properties through heat treatment, enhancing versatility. The alloy maintains high strength and stability under extreme conditions, including elevated temperatures and corrosive environments. Additionally, it offers good formability and weldability, enabling ease of fabrication for complex structures. With low maintenance requirements and superior durability, Stainless Steel 17-7 PH Channel is a cost-effective choice for aerospace, automotive, and industrial applications.
Yes, we offer custom sizes for Stainless Steel 17-7 PH Channel to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Stainless Steel 17-7 PH Channel find extensive application in aerospace components, pressure vessels, structural frameworks, chemical process systems, and nuclear waste handling systems. Their strength-to-weight ratio is very high, which makes them the best for load bearing structures where space is a constraint and weight needs to be minimized. They are also used in medical devices, springs, and fasteners because they possess high dimensional stability and resistance to distortion. SS 17-7 PH channels are especially prized in applications where both mechanical strength and protection from corrosive or high-stress conditions are needed, guaranteeing long service life and predictable behavior under extreme operating requirements.
