Varun Sheets and Plates is a reliable supplier and manufacturer of SA537 Class 2 Boiler Sheets and Plates in Dubai, UAE, providing high-strength steel plates designed to be used in pressure vessels and high-temperature applications. SA537 Class 2 is a quenched and tempered carbon-manganese-silicon steel plate that boasts excellent mechanical properties and good resistance to high pressure. Varun supplies these plates in different thicknesses and sizes according to international standards. Catering to industries like oil and gas, petrochemical, and power generation, Varun provides quality, accuracy, and timely delivery for high-demand industrial use.
SA537 Class 2 Boiler Sheets and Plates consist of carbon (up to 0.24%), manganese (1.10–1.60%), silicon (0.15–0.50%), phosphorus (up to 0.035%), and sulfur (up to 0.035%). These plates are heat-treated by quenching and tempering to improve their mechanical strength. They have a minimum tensile strength of 620–795 MPa and a minimum yield strength of 450 MPa. SA537 Class 2 possesses high toughness, impact resistance, and weldability and is thus suitable for critical pressure-containing vessels that are exposed to higher pressure and temperature conditions.
Grade : ASME SA 537 CL.2 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Tensile (MPa) | Yield (MPa) | Elongation |
| SA537 Class 2 | Quenched and tempered | 550–690 | 415 | 22% |
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 2 boiler sheet and plate offer excellent strength and durability, making them ideal for pressure vessels and boiler applications. They are heat-treated to improve their hardness, ensuring resistance to high-pressure environments and elevated temperatures. The material demonstrates excellent weldability, enabling easy fabrication into complex shapes. Its resistance to corrosion and cracking under stress makes it suitable for harsh industrial environments. Additionally, SA537 Class 2 provides good toughness and impact resistance, ensuring long-term reliability in demanding applications such as power plants and chemical processing.
SA537 Class 2 Boiler Plates and Sheets are applied extensively to the construction of high-pressure tanks, heat exchangers, and reactors in oil refining, chemical processing, and power generation industries. These plates’ superior strength and impact resistance qualify them for use in applications where the structural integrity in terms of resisting extreme stress is critical. SA537 Class 2 Plates are usually chosen for application in pressurized tanks, gas separators, and steam boilers. SA537 Class 2 is especially prized for its toughness, stable behavior under dynamic loading, and application for heavy-duty welded constructions in critical pressure regimes.
