Varun Sheets and Plates is a leading producer and supplier of Stainless Steel 347 Foils in Dubai, UAE, with high-performance thin metal sheets resistant to corrosion for demanding industrial uses. SS 347 is niobium-stabilized austenitic stainless steel with outstanding resistance to intergranular corrosion, even in the case of welding and high-temperature exposure. Varun offers SS 347 foils in a range of widths and thicknesses, made to precision standards such as ASTM A240. SS 347 foils are heavily employed in industries including aerospace, chemical processing, heat exchangers, and electronics, where stability, strength, and oxidation resistance are a must.
Stainless Steel 347 Foils have 17–20% chromium, 9–13% nickel, and columbium (niobium) as stabilization agents, with a maximum carbon content of 0.08%. These foils provide tensile strength of approximately 515 MPa and yield strength of 205 MPa. These foils have good creep resistance and oxidation resistance up to 870°C temperature. The addition of niobium inhibits carbide precipitation, thus improving weldability and long-term strength in high-temperature service. SS 347 foils do not loose their mechanical strength and flexibility even when subjected to cyclic thermal loading.
igh-temperature service. SS 347 foils do not loose their mechanical strength and flexibility even when subjected to cyclic thermal loading.
| Item | Stainless Steel 347 foil(Hot rolled, cold rolled) | |
| Thickness | 0.025 to 3 mm and as per Customer Requirement | |
| Width | 3 mm to 2000 mm and as per Customer Requirement | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | the surface and finish of stainless steel 347 foil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 347 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Properties | Metric | Imperial |
| Tensile strength (transverse at room temperature) | 685 MPa | 99400 psi |
| Tensile strength (longitudinal at room temperature) | 696 MPa | 101000 psi |
| Yield strength (transverse at room temperature) | 292 MPa | 42400 psi |
| Yield strength (longitudinal at room temperature) | 301 MPa | 43700 psi |
| Compressive yield strength | 365 MPa | 52900 psi |
| Elastic modulus | 197 GPa | 28573 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (longitudinal at room temperature) | 56% | 56% |
| Elongation at break (transverse at room temperature) | 62.50% | 62.50% |
| Hardness, Rockwell B (transverse at room temperature) | 85 | 85 |
| Hardness, Rockwell B (longitudinal at room temperature) | 85 | 85 |
DIN 1.4550 Foils offer several advantages, particularly in high-temperature and corrosive environments. The addition of niobium stabilizes the material, preventing carbide precipitation and ensuring excellent resistance to intergranular corrosion, especially in welded structures. It also provides outstanding oxidation and thermal stability, making it ideal for applications exposed to elevated temperatures. The material’s exceptional strength, durability, and weldability make it versatile for a wide range of industrial applications. Stainless Steel 347 Foils are widely used in the aerospace, chemical, and power generation industries, offering reliable performance and long-lasting resistance under harsh conditions.
| STANDARD | UNS | JIS | WERKSTOFF NR. |
| SS 347 | S34700 | SUS 347 | 1.4550 |
Stainless Steel 347 Foils are applied in aircraft parts, thermal insulation, exhaust liners, expansion joints, and flexible connectors because of their slim profile and heat resistance. They are applied in chemical and petrochemical plants as liner materials, bellows, and catalyst bed supports. SS 347 foils are also perfectly suited for electronics shielding, filtration systems, and precision-crafted parts where space, weight, and corrosion resistance matter. Their strength, formability, and thermal stability make them a first preference for both heavy-duty and specialty applications at high temperatures.
