Located in Dubai, United Arab Emirates, Varun Sheets and Plates is a well-known producer and supplier of premium EN 9 Sheets and Plates that are intended to provide exceptional performance in demanding engineering applications. EN 9 steel products are well-known for having a medium carbon content and superior wear resistance, making them perfect for parts that need to have a high level of strength and surface hardness. Varun Sheets and Plates guarantees timely delivery, exact manufacturing, and stringent quality control in both the UAE and foreign markets. The company, which serves the construction, automotive, and machinery industries, is dedicated to offering EN 9 steel sheets and plates that are dependable and long-lasting for a variety of industrial applications.
Carbon (0.50–0.60%), manganese (0.70–0.90%), and trace amounts of silicon, sulphur, and phosphorus make up EN 9 Sheets and Plates, which are medium carbon steel materials. Depending on heat treatment, these sheets have a good yield strength of 400–500 MPa and a tensile strength of 600–800 MPa. Additionally, the material offers good hardness, ductility, and toughness (up to 200–250 HB when left untreated, and higher when heated). EN 9 steel is appropriate for high-strength and wear-resistant applications because it works well with surface hardening processes like induction or flame hardening.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
EN 9 sheets and plates offer a number of advantages including excellent tensile strength and hardness, making them suitable for heavy duty applications The high carbon content of the alloy provides excellent durability and corrosion resistance, and provides long-term stability in hard surfaces. EN 9 also provides excellent machining, making it easier to work in a variety of shapes and sizes. It exhibits excellent fatigue resistance, making it ideal for components subjected to repeated stresses, such as gears, shafts and axles. Because of its versatility and reliability, EN 9 is widely used in the automotive engineering and construction industry.
Yes, we offer custom sizes for EN 9 Sheet and Plates to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Applications requiring high surface hardness and moderate tensile strength frequently use EN 9 Sheets and Plates. They are frequently used in the production of automotive parts like spindles, axles, shafts, and gears. EN 9 steel is utilised in the engineering and construction industries for railings, rollers, industrial tools, and structural components. Additionally, the material is appropriate for high-stress and wear machine parts like press tools, coupling rods, and crankshafts. Its suitability for precision and heavy-duty engineering applications in a range of industrial sectors is further increased by its compatibility with hardening treatments.
