Varun Sheets and Plates Manufacturer and Suppliers in Dubai, UAE, is a reliable supplier of Haynes 25 / L605 Sheets and Plates with high-performance materials for use in applications that require exceptional strength, wear resistance, and thermal stability at high temperatures. Known for providing best-quality cobalt-based alloy products, Varun makes sure each sheet and plate fulfills international standards and complies with customer requirements. Supplying aerospace, power, chemical, and medical industries throughout the UAE and worldwide, we pride ourselves on excellence in quality of materials, timely delivery, and proactive customer service.
Haynes 25 / L605 Plates and Sheets are fabricated from cobalt-chromium-tungsten-nickel alloy possessing superior strength, oxidation resistance, and thermal stability at temperatures up to 1095°C. The alloy is generally constituted with cobalt (around 51%), chromium (20%), tungsten (15%), and nickel (10%). It has a tensile strength of approximately 960 MPa and excellent formability and weldability. Produced in accordance with AMS 5537 and ASTM F90 specifications, Varun provides Haynes 25 / L605 plates and sheets in various sizes and thicknesses for application in severe high-temperature and corrosive conditions.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
| STANDARD | Material No | EN Designation | UNS | Alloy |
| Haynes 25 / L605 | 2.4964 | CoCr20W15Ni | R30605 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes 25 (L605) sheets and plates provide exceptional high-temperature strength and outstanding resistance to oxidation, carburization, and sulfidation, making them ideal for harsh environments They wear well and resist corrosion ensure durability, especially in chemical applications and aerospace applications . Excellent mechanical strength is maintained up to 1800°F (980°C) and allows for high formability and weldability. The cobalt-based structure of the compound provides durability and creep resistance, supporting reliability under extreme stresses. These features make Haynes 25 paper and plate the preferred choice for high-performance applications in hostile environments.
| Density | Lb/in3 | 0.327 |
| g/cm3 | 9.07 | |
| Melting Point | oF | 2425-2570 |
| oC | 1330-1410 | |
| Specific Heat | Btu/lb-oF | 0.096 |
| J/kg-oC | 403 | |
| Expansion Coefficient | 25-100oC | 12.8 |
| 70-200oF | 7.1 | |
| Thermal Conductivity | W/m-oC | 10.5 |
| BTU-in/hr-ft2–oF | 72 | |
| Electrical Resistivity | µohm-cm | 88.6 |
| µohm-in | 34.9 |
