Varun Sheets and Plates is a trusted producer and supplier of Nickel Alloy 201 Sheets and Plates in Dubai, UAE, with high-quality commercially pure nickel products that ensure superior corrosion resistance and mechanical strength. Nickel Alloy 201 is comparable to Alloy 200 but with less carbon content, providing enhanced resistance to intergranular attack during welding. Varun provides these plates and sheets in different sizes and thicknesses, made as per international standards. Catering to industries like chemical processing, electronics, aerospace, and marine, Varun provides timely delivery and high-quality products.
Nickel Alloy 201 Plates and Sheets consist mostly of nickel (min 99%), and minor levels of iron (max 0.40%), manganese, silicon, and copper. Low carbon levels are present (max 0.015%). This alloy has a tensile strength of approximately 310 MPa and yield strength of 105 MPa with superior ductility and toughness. Low carbon content improves weldability as well as resistance to sensitization. Nickel Alloy 201 has superior corrosion resistance to alkalis, organic acids, and oxidizing conditions, and good thermal and electrical conductivity.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 Sheets and Plates find extensive use in chemical processing equipment, heat exchangers, marine use, electrical and electronic components, and aerospace components. The caustic resistance of the alloy, combined with its strength and durability, makes it suitable for the production of storage tanks, piping systems, and corrosion-resistant structural parts. Nickel Alloy 201 is particularly favored where welding is recurrent, since its low carbon content minimizes the possibility of carbide precipitation. This guarantees long term performance and integrity in harsh industrial conditions.
