Varun Sheets and Plates is a well-respected manufacturer and supplier of Aluminium 2024 T3511 Plates and Sheets based in Dubai, UAE. We specialize in high-performance aluminium products tailored for precision engineering applications. Our 2024 T3511 plates are renowned for their exceptional strength, fatigue resistance, and machinability, making them a go-to choice in demanding fields like aerospace and structural engineering. With cutting-edge manufacturing facilities and rigorous quality control, we offer customized sizes, finishes, and prompt delivery to meet global standards. Varun Sheets and Plates is your trusted partner for top-notch aluminium solutions across various industrial sectors in the UAE and beyond.
Aluminium 2024 T3511 Plates and Sheets are made up of approximately 90.7% Aluminium, 3.8–4.9% Copper, 1.2–1.8% Magnesium, and 0.3–0.9% Manganese, along with trace amounts of Silicon, Iron, and Zinc. In the T3511 temper, the material undergoes stress relief, cold working, and natural aging, which boosts its structural integrity and mechanical strength. This alloy boasts a tensile strength of around 470 MPa, a yield strength of 325 MPa, and an elongation of about 10–15%, providing excellent fatigue resistance and workability for precision-critical applications.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 2024 T3511 Sheets and Plates offer outstanding advantages, including exceptional strength and fatigue resistance, making them ideal for high-performance aerospace, military, and engineering applications. The T3511 temper enhances the material’s structural integrity, ensuring reliability in demanding environments. These sheets and plates feature an excellent strength-to-weight ratio, critical for weight-sensitive industries like aviation. Their superior machinability allows for precise fabrication and complex designs. While the alloy has moderate corrosion resistance, it can be treated for enhanced durability, ensuring long-lasting performance. Aluminium 2024 T3511 is a top choice for high-stress applications.
Yes, we offer custom sizes for Aluminium 2024 T3511 Plates and Sheets to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
You’ll find Aluminium 2024 T3511 Plates and Sheets primarily in aerospace components like wing spars, fuselage structures, and bulkheads, thanks to their impressive strength-to-weight ratio and ability to withstand cyclic loading. They’re also perfect for military applications, transportation parts, marine hardware, and high-performance automotive components. Their stress-relieved properties help minimize distortion during machining, making them ideal for CNC applications. While the corrosion resistance is moderate, these sheets are often clad or coated for added protection, ensuring they remain durable in structurally demanding and safety-critical environments.
