Varun Sheets and Plates stands out as a premier manufacturer and supplier of Aluminium 2024 Plates and Sheets in Dubai, UAE. We pride ourselves on delivering top-notch aluminium products that meet the rigorous demands of various industries. Our Aluminium 2024 sheets are celebrated for their impressive strength-to-weight ratio and outstanding fatigue resistance, making them perfect for applications where structural integrity is non-negotiable. Crafted with precision and rigorously tested for quality, we offer these plates in a range of sizes and finishes, catering to clients in the aerospace, transportation, and military sectors. With our commitment to reliable service, prompt delivery, and competitive pricing, Varun Sheets and Plates is your go-to source for aluminium solutions in the UAE.
Aluminium 2024 Plates and Sheets are primarily composed of Aluminium (90.7%), Copper (3.8–4.9%), Manganese (0.3–0.9%), and Magnesium (1.2–1.8%), along with trace amounts of Iron and Silicon. This alloy is well-known for its high strength and fatigue resistance, although it does have lower corrosion resistance. Its mechanical properties boast a tensile strength of up to 470 MPa, a yield strength of around 325 MPa, and an elongation of about 10–15%, making it ideal for applications that demand both strength and durability under cyclic loads.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 2024 Sheets and Plates offer several advantages, including exceptional strength and high fatigue resistance, making them ideal for aerospace, military, and structural applications. The high copper content enhances its mechanical properties, providing superior strength-to-weight ratio, which is essential in weight-sensitive industries like aviation. Aluminium 2024 also offers good machinability, allowing for complex designs and precise fabrication. While it has moderate corrosion resistance, it can be treated with coatings for enhanced durability. Its high performance, combined with excellent wear resistance, makes it a preferred choice for demanding environments.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
In the aerospace industry, Aluminium 2024 Plates and Sheets are extensively utilized for aircraft structures, fuselage frames, and wing skins, thanks to their remarkable strength and fatigue resistance. They also find applications in automotive parts, military equipment, marine components, and structural projects where strength is paramount. While they aren’t naturally resistant to corrosion, they are often anodized or coated with a pure aluminium layer for added protection. The alloy’s capacity to endure heavy stress and vibration makes it a top choice for high-performance, high-load environments.
