Varun Sheets and Plates is a renowned manufacturer and supplier of Nickel Alloy 200 Channels in Dubai, UAE, offering high-quality, commercially pure nickel structural products known for their superior corrosion resistance and mechanical strength. Nickel Alloy 200 Channels find extensive application in industrial processes requiring resistance to alkalis, reducing agents, and elevated temperatures. Varun provides these channels in different sizes and specifications meeting international standards to cater to the stringent requirements of chemical processing, marine, aerospace, and power generation industries.
Nickel Alloy 200 Channels contain a minimum of 99.6% nickel with negligible quantities of iron (max 0.40%), manganese, carbon, and silicon. This composition provides a tensile strength of about 340 MPa and a yield strength close to 105 MPa. The alloy has great resistance to caustic alkali corrosion, dry gases corrosion, and corrosion by neutral or alkaline salt solutions, as well as high thermal and electrical conductivity. It also has great ductility and toughness at cryogenic temperatures and is good at weldability and formability.
Specifications : ASTM B160 / ASME SB160
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 Channel offers several advantages, including exceptional corrosion resistance, particularly in alkaline environments and organic acids. It maintains strength and toughness at high and low temperatures, making it ideal for demanding applications. Its excellent weldability and formability provide versatility in manufacturing, and its resistance to various forms of corrosion, such as pitting and crevice corrosion, ensures longevity and reliability. Additionally, it offers superior resistance to atmospheric oxidation and maintains high thermal and electrical conductivity, making it suitable for industries like chemical processing and electronics.
Nickel Alloy 200 Channels are typically used in structural frameworks, support beams, and corrosion-resistant frameworks of chemical plants, marine ships, and aerospace components. Their ability to withstand aggressive atmospheres and high temperatures qualifies them for use in the handling of corrosive and caustic chemicals. These channels are also used in electrical and electronic devices because of their excellent conductivity and magnetic characteristics. Nickel Alloy 200 Channels offer strength, durability, and corrosion resistance, and therefore the best application for their demanding structural purposes in severe industrial conditions.
