Varun Sheets and Plates is a trustworthy manufacturer and supplier of Inconel 718 Sheets and Plates in Dubai, UAE, providing high-performance nickel-based superalloys designed for extreme conditions. Inconel 718 is a precipitation-hardenable alloy that has excellent strength, corrosion resistance, and stability at elevated temperatures. It has a broad application in the aerospace, power generation, chemical processing, and marine sectors. Varun offers these sheets and plates in different thicknesses and sizes, accurately produced to satisfy international standards and stringent specifications, with remarkable strength and performance under severe operating conditions.
Inconel 718 Sheets and Plates are mainly made of nickel (50–55%) and chromium (17–21%) along with iron, niobium, molybdenum, titanium, and aluminum additions. The alloy possesses a tensile strength of up to 1240 MPa and superior yield strength following age hardening. It retains mechanical strength up to 700°C and offers excellent corrosion, oxidation, and creep resistance. Inconel 718 also contains excellent weldability, fatigue life, and high impact and tensile strength, which makes it suitable for the most severe, stress-packed environments.
| Specification | ASTM B670 UNS N07718, ASME SB670 |
|---|---|
| Sizes | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 100 mm Thk |
| Width | 10-2500mm |
| Length | 2m, 2.44m, 3m, or as required |
| ASTM | ASTM B670 |
| AMS | AMS 5596 |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Stock in form of | Alloy 718 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Material | JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW7182, etc DIN:H-Ni99.96, H-Ni99.95, H-Ni99.92, H-Ni99.90, H-Ni99.5, H-Ni99, etc |
| Why choose Superior Steel Overseas |
|
| Inconel 718 profiling | To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Inconel 718 | 2.4668 | N07718 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 718 Sheets and Plates offer numerous advantages, making them a preferred choice across industries. Their exceptional corrosion resistance, even in highly acidic and oxidizing environments, ensures durability in harsh conditions. They exhibit outstanding high-temperature strength and stability, performing reliably up to 700°C. These sheets and plates resist stress corrosion cracking and crevice corrosion, ensuring structural integrity under pressure. Their excellent weldability and machinability make fabrication easier, while their ability to retain mechanical properties in extreme environments makes them ideal for aerospace, marine, chemical processing, and power generation applications.
Yes, we offer custom sizes for Inconel 718 Sheets and Plates to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
| Inconel 718 Plate Metric Dimensions | ||
|---|---|---|
| Surface finish | Thickness (mm) | Width (mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
| Thickness | Plate Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Inconel 718 Sheets and Plates are extensively used in critical service parts like components of turbines, engine parts of jets, rocket motors, nuclear reactors, pressure vessels, and storage in cryogenic. These plates are best suited where excellent strength and resistance to harsh temperature and corrosion are necessary. The alloy’s mechanical properties combined with stability establish it for applications in aerospace and gas turbine parts, industrial tooling, fasteners, and structural components in harsh environments. Inconel 718 provides reliable performance, extended service life, and safety in the most demanding industrial applications.
