Varun Sheets and Plates is a trusted manufacturer and supplier of superior quality Inconel 617 Sheets and Plates in Dubai, UAE. Based in the Middle East, Varun enjoys a robust market presence and is recognized for supplying top-grade materials that are compliant with international standards. Our Inconel 617 products are designed to perform under challenging conditions, such as high-temperature and corrosive environments. We cater to a broad spectrum of industries, including petrochemical and power generation, aerospace and heat treatment. Through precision manufacturing and customer-centric focus, Varun is a reliable partner for long-lasting and high-performance Inconel 617 solutions.
Inconel 617 Sheets and Plates consist primarily of nickel (about 44.5–62%), along with large proportions of chromium (20–24%), cobalt (10–15%), and molybdenum (8–10%), and include iron and minor elements such as aluminum and carbon. This alloy possesses remarkable high-temperature strength and oxidation resistance. It is mechanically characterized by tensile strength of as high as 690 MPa, yield strength of approximately 310 MPa, and fair elongation. Inconel 617 also shows superior structural integrity when subjected to long-term thermal exposure and mechanical loading and thus is perfect for applications in harsh environments like gas turbines and chemical processing facilities.
Standards : ASTM B168 / ASME SB168, SAE AMS 5888, SAE AMS 5889
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Thickness : 0.1mm to 12 mm Thk
Length : 500mm to 12000mm
Width : 100mm to 3000mm
| Element | Yield Strength | Tensile Strength | Elongation % | Reduction of Area | Hardness, BHN | ||
| ksi | MPa | ksi | MPa | ||||
| Inconel 617 | 50.9 | 351 | 109.5 | 755 | 58 | – | 173 |
| Grade Inconel 617 | Ni | Cr | Fe | Mo | Co | Mn | Cu | Al | Ti | Si | C | S | P |
| MIN | 44.2 | 20.0 | – | 8.0 | 10.0 | – | – | 0.8 | – | – | – | – | – |
| MAX | 56.0 | 24.0 | 3.0 | 10.0 | 15.0 | 0.5 | 0.5 | 1.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 |
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 617 Sheets and Plates offer numerous advantages, making them a preferred choice for high-performance applications. They exhibit excellent resistance to oxidation and carburization, even at temperatures exceeding 1000°C. Their superior mechanical strength and exceptional creep resistance ensure durability under extreme pressure and heat. The alloy’s corrosion resistance extends to acidic and high-moisture environments, enhancing its versatility. Additionally, its thermal stability and weldability make it easy to fabricate into complex structures. These properties make Inconel 617 ideal for aerospace, chemical processing, power generation, and gas turbine components.
Yes, we offer custom sizes for Inconel 617 Sheets and Plates to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
| Dimension (mm) | KG P/M2 |
| 0.5 X 1000 X 2000 | 4.5 |
| 0.7 X 1219 X 3048 | 6.3 |
| 0.9 X 1219 X 3048 | 8.1 |
| 1.2 X 1219 X 3048 | 10.8 |
| 1.6 X 1200 X 3048 | 14.4 |
| 2.0 X 1219 X 3048 | 18.0 |
| 3 X 1200 X 3000 | 27.0 |
| 3.18 X VARIOUS ANN | 28.6 |
| Thickness | Plate Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Inconel 617 Sheets and Plates find extensive application in products where oxidation and corrosion resistance and high-temperature strength are essential. Some common applications are components of gas turbines, combustion chambers, heat exchangers, ducting systems, and furnace parts for industrial purposes. In power generation, particularly in newer ultra-supercritical steam cycles, Inconel 617 is a preferred material because of its high-temperature strength. Its carburization, sulfidation, and oxidation resistance also qualify it for petrochemical processing, marine engineering, and aerospace uses. Its high formability and weldability further enhance its versatility in the production of high-performance parts.
