Varun Sheets and Plates is a reliable manufacturer and supplier of Incoloy 800 / 800H / 800HT Coil and Slitting Coil, proudly based in Dubai, UAE. We specialize in high-performance nickel-iron-chromium alloy coils that are engineered for outstanding strength, thermal stability, and impressive resistance to oxidation and carburization, even in high-temperature settings. These coils find their way into various applications, including heat treating equipment, petrochemical processing, power generation, and furnace components. Adhering to ASTM B409 standards, our Incoloy 800 series coils come in a range of tempers, thicknesses, and widths, along with precision slitting services tailored to meet the specific needs of customers both in the UAE and around the globe.
Typically, Incoloy 800 / 800H / 800HT Coils are made up of 30–35% nickel, 19–23% chromium, and small amounts of aluminum and titanium. The 800H and 800HT versions are designed to offer improved creep and rupture strength thanks to their carefully controlled carbon and aluminum/titanium content. These alloys excel in resisting oxidation, carburization, and stress corrosion cracking, boasting tensile strength between 450 to 650 MPa and reliable performance at temperatures reaching up to 1100°C (2012°F).
| Specification | ASTM B409 / ASME SB409 |
|---|---|
| Thickness | Plate 0125″ to 5.00″ / Sheets 008″ to .0125″ |
| Sheet / Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheet / Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Sheets Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Plate / Sheets Size | 15NB to 150NB In |
| Tempers | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Coils Thickness | 0.3 mm to 120 mm |
| Coils Length | AS PER CUSTOMER’S REQUIREMENT |
| Form | Sheets, Plates, Coils, Strips, Circle, Ring, Disc, Foils |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4959 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Steel Coil | Size (mm) | Weight per Coil (Kg) | Size(mm) | Weight per Coil (Kg) |
|---|---|---|---|---|
| Incoloy 800/800H/800HT Coil | 4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
| Incoloy 800/800H/800HT Coil | 4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
| Incoloy 800/800H/800HT Coil | 2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
| Incoloy 800/800H/800HT Coil | 3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
| Incoloy 800/800H/800HT Coil | 4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
| Incoloy 800/800H/800HT Coil | 2500 x 1250 x 5.0 | 133.0 |
Incoloy 800, 800H and 800HT coils and offer many advantages, such as exceptional resistance to oxidation, carburization and high temperature corrosion, making them ideal for harsh environments Their high nickel content ensures high thermal stability and efficiency , while the chromium content gives it better resistance to oxidation Incoloy 800H and The 800HTs also have enhanced creep and fracture strength due to high carbon and titanium content. These alloys exhibit excellent weldability, excellent long-term performance and durability, making them ideal for use in applications such as power generation, chemical processing and heat treatment
Incoloy 800, 800H, and 800HT Coil and Slitting Coil are commonly utilized in high-temperature applications such as furnace retorts, radiant tubes, heat exchangers, hydrocarbon cracking units, and superheaters in power plants. Their stability during thermal cycling and in corrosive environments makes them perfect for components that endure prolonged heat and chemical exposure. Additionally, these coils are essential in the fabrication of welded structures and pressure vessels. With precise slitting, excellent workability, and remarkable high-temperature resistance, these alloys are the go-to choice for challenging thermal and chemical service conditions.
