Varun Sheets and Plates is a well-respected manufacturer and supplier of Incoloy 800 / 800H / 800HT Channels, proudly based in Dubai, UAE. They specialize in high-performance alloy products that are specifically engineered to endure extreme conditions. These channels boast remarkable resistance to high-temperature corrosion and oxidation, making them perfect for a variety of industrial applications. Varun’s dedication to quality, precision engineering, and timely delivery means that clients in sectors like power generation, petrochemicals, and marine industries can count on them for reliable and durable solutions. With a strong focus on international standards, Varun Sheets and Plates has built a solid reputation both in the UAE and in global markets.
The Incoloy 800 / 800H / 800HT Channels are made up of nickel (30–35%), chromium (19–23%), and iron (the balance), along with carefully controlled amounts of aluminum, titanium, and carbon. These alloys provide excellent mechanical stability and resist oxidation and carburization in high-temperature settings. The 800H and 800HT variants are specially treated to enhance their creep and rupture resistance. Typical mechanical properties include a tensile strength of about 520 MPa, a yield strength of around 205 MPa, and an elongation of 30%, making these channels highly suitable for long-term performance in challenging operating conditions.
Specifications : ASTM B408 / ASME SB408
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800, 800H, and 800HT channels offer several advantages, including exceptional resistance to oxidation, carburization, and thermal degradation at high temperatures. These alloys maintain strength and stability in extreme environments, making them ideal for applications in chemical processing, power plants, and heat exchangers. Incoloy 800H and 800HT variants provide enhanced creep strength and resistance to thermal fatigue, with 800HT offering superior stability at elevated temperatures. Additionally, these alloys exhibit excellent weldability, formability, and corrosion resistance, ensuring long-term reliability and durability in challenging industrial conditions.
Yes, we offer custom sizes for Incoloy 800 / 800H / 800HT Channel to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
Incoloy 800 / 800H / 800HT Channels are commonly utilized in applications that demand superior strength and oxidation resistance at elevated temperatures. They are found in heat exchangers, furnace components, petrochemical reactors, power plant superheaters and reheaters, as well as nuclear steam generators. Their thermal stability and corrosion resistance make them ideal for pressure vessels, structural frameworks, and high-temperature piping systems. In industries such as chemical processing, oil refining, and power generation, these channels play a crucial role in ensuring safety and efficiency, even in the most aggressive environments, by maintaining their structural integrity under thermal and mechanical stress.
