Varun Sheets and Plates is a well-known supplier and manufacturer of MONEL 400 Foils in Dubai, UAE. The organization specializes in delivering high-quality metal products that conform to international industry standards. MONEL 400 is a nickel-copper alloy that is commonly known for its superior corrosion resistance, especially in seawater and acidic mediums. The foils made by Varun Sheets and Plates are carefully manufactured for accuracy and strength to provide industries that are dependent on high-performance materials with the best possible solutions to their individual requirements.
MONEL 400 contains a major percentage of 63% nickel, 28-34% copper, along with minor percentages of iron, manganese, and silicon. It has very good mechanical properties, including high tensile strength of up to 70,000 psi and high corrosion resistance in extreme environments like seawater, acids, and alkalis. The alloy retains its strength and stability over a wide range of temperatures, from cryogenic temperatures to 1000°F (538°C). It is also weldable and formable to a high degree, a factor that makes it ideal to use when producing foils that need flexibility and withstand extreme conditions.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel DIN 2.4360 Foils offer outstanding advantages, including excellent corrosion resistance in seawater, acidic, and alkaline environments, making them ideal for marine and chemical applications. They possess high mechanical strength and durability, ensuring long-lasting performance under extreme conditions. Monel 400 foils maintain stability across a wide temperature range, providing reliable functionality in high-temperature settings. Their excellent resistance to stress corrosion cracking and pitting enhances their dependability in critical applications. Easy to fabricate and weld, these foils are versatile for use in diverse industries, including aerospace, marine, chemical processing, and electrical systems.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
MONEL 400 Foils find extensive application across industries where materials are subjected to corrosive exposure. These are used quite extensively in marine applications, including propeller blades, valve components, and heat exchangers, where corrosion resistance against seawater is important. MONEL 400 foils are also employed in chemical processing, aerospace, and power generation sectors for reactor cores, heat exchangers, and pressure vessels. Their resistance to acidic and alkaline materials while retaining mechanical strength positions them as a must within harsh environments. In addition, the foils are applied to numerous electrical and electronics uses, guaranteeing effective performance within harsh conditions.
