Varun Sheets and Plates Supplier and Manufacturer, Dubai, UAE, is a key supplier of precision-engineered Invar Sheets and Plates to industries requiring high dimensional stability under thermal stress. With their technical know-how and quality focus, Varun offers Invar products to the aerospace, electronics, tooling, and science industries. With cutting-edge processing facilities and compliance with global standards, the company supplies Invar materials in bespoke sizes and finishes to clients from the UAE and international markets with accuracy and speed.
Invar Sheets and Plates consist of a nickel-iron alloy containing about 36% nickel and 64% iron. This alloy has a very distinctively low coefficient of thermal expansion (~1.2 × 10⁻⁶/°C between 20°C and 200°C), which provides unparalleled dimensional stability over temperatures. Mechanical properties are tensile strength 450–550 MPa and yield strength approximately 270–300 MPa. Invar is usually supplied in annealed condition for improved machinability and can be obtained in sheet and plate thicknesses from 0.1 mm to 50 mm, according to ASTM F1684 or UNS K93600 specifications.
| Standards : | Per Chem Mil-I-23011C CL 7, Boeing D-33028, ASTM B753, ASTM F1684, ASTM F30 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 42 | 1.3917 | K94100 |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 42 | KSI (MPa) 36 / (248) | KSI (MPa) 71 / (490) | 40 % |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Density | 0.293 lb/cu in |
| Specific Gravity | 8.12 |
| Curie Temp | 715 oF or 380oC |
| Melting Point | 2600 oF or 1427oC |
| Electrical Resistivity | 66 Micro-ohm-cm or 400 ohm-cir mil/ft |
| Thermal Conductivity | 10.7 W/cm oC or 74.7 BTU-in/sq. ft-hr |
| Specific Heat | 0.12 Cal/g- oC |
| Thermal Expansion | 5.0 ppm / oF (75oF to 842oF) or 9.0 ppm / oC (25oC to 450oC) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Invar 42 sheets and plates offer several advantages, primarily their low coefficient of thermal expansion (CTE), making them ideal for precision applications that require minimal dimensional changes with temperature fluctuations. This makes them highly effective in industries like aerospace, electronics, and cryogenics. Invar 42 also exhibits excellent stability, high fatigue resistance, and good machinability. Its ability to retain dimensional accuracy in varying conditions ensures reliability in sensitive instruments and equipment. Additionally, the alloy’s good weldability and strength enhance its versatility across various engineering and manufacturing sectors.
Yes, we offer custom sizes for Invar 42Sheets and Plates to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
Invar Sheets and Plates are employed in situations where accuracy and low thermal expansion are essential. Some of these applications are aerospace tooling, satellite and telescope parts, cryogenic tanks, semiconductor production equipment, and precision instruments. Invar is also used in bimetallic thermostats, composite moulds, and in the housings of laser systems. Its shape and alignment retention across broad temperature ranges make it a must-have in high-precision engineering. Varun’s Invar Sheets and Plates are relied upon for their consistency, flatness, and stability, providing the best performance in delicate and high-stakes industrial processes.
