Varun Sheets and Plates is a reliable manufacturer and supplier of Duplex Steel S32205 Channels in Dubai, UAE, that provides high-performance structural components for challenging industrial applications. With an eye on quality, durability, and precision, the company produces corrosion-resistant products appropriate for the oil and gas, marine, chemical, and construction sectors. Duplex Steel S32205 Channels are produced with sophisticated methods and rigorous quality checks to make them conform to international standards. Famous for their mechanical strength and durable life, these channels prove best for structural support in those areas that are subjected to high stress, pressure, and corrosive substances.
Duplex Steel S32205 Channels contain around 22% chromium, 5-6% nickel, 3% molybdenum, and nitrogen, having superior corrosion resistance in chloride and acidic conditions. Having a duplex microstructure of ferrite and austenite, the channels possess high mechanical strength and toughness. The average mechanical properties are tensile strength at 620 MPa, yield strength at 450 MPa, and elongation at 25%. The Duplex Steel S32205 Channel is highly appreciated for its weldability, pitting and crevice corrosion resistance, and capability to sustain rough and corrosive industrial environments.
Specifications : ASTM A182 / ASME SA182
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex 2205 | 1.4462 | S32205 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Duplex Steel S32205 Channel offers several advantages, including exceptional resistance to corrosion, particularly pitting, crevice, and stress corrosion cracking, making it ideal for harsh environments like chemical processing and marine applications. Its high strength, with a yield strength of 450 MPa and tensile strength of 620 MPa, provides superior durability compared to conventional stainless steels. The alloy’s excellent weldability and formability enhance its versatility in fabrication. Additionally, S32205 maintains a good balance of mechanical properties and corrosion resistance, ensuring longer service life and reduced maintenance costs in demanding industries.
Yes, we offer custom sizes for Duplex Steel S32205 Channel to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae
