Varun Sheets and Plates specializes in Dubai, UAE, manufacturing quality metal products, including a wide range of sheets and plates We are committed to providing durable and precisely designed products for a range of industrial applications. In addition, we offer copper nickel 70/30 channel, known for their excellent corrosion resistance, strength and reliability in harsh environments. Our products meet the needs of a variety of businesses, deliver superior performance, and are backed by exceptional customer service and competitive pricing.
| Specifications | : | ASTM B151 / ASME SB151 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Cu-Ni 70/30 Angle | : | 5mm to 9mm |
| Cu-Ni 70/30 Channel | : | 40mm*20mm~300mm*300mm |
| Cu-Ni 70/30 Beam | : | 3″ thru 12.31″ |
| Cu-Ni 70/30 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 70/30 Channel offer several advantages. They are insoluble, especially in ambient seawater, making them ideal for marine applications. The alloy also provides excellent resistance to biofouling, providing durability under extreme conditions. Its strength and compression durability make it suitable for high-pressure environments. In addition, CuNi 70/30 has excellent thermal conductivity and is easy to weld, providing versatility in manufacturing. Its low maintenance requirements and high resistance to scaling and pitting further enhance its industrial appeal.
Copper Nickel 70/30 Channel are widely used in the marine and industrial industries due to their excellent corrosion resistance, especially in seawater Commonly found in heat exchangers, condensate pipes, desalination plants, piping systems on ships and offshore platforms. Resistance to biofouling makes this compound ideal for marine cooling systems. It is used in the pharmaceutical industry, power plants and water treatment plants. In addition, CuNi 70/30 has been used in condenser and evaporator system design due to its stable performance in harsh environments.
