Aluminium 5005 Coils

Varun Sheets and Plates is a well-respected manufacturer and supplier of Aluminium 5005 Coils based in Dubai, UAE. We take pride in providing top-notch aluminium solutions tailored for a variety of industries. Aluminium 5005 is celebrated for its impressive corrosion resistance, sleek surface finish, and moderate strength, making it a fantastic choice for both decorative and practical uses. At Varun Sheets and Plates, we offer Aluminium 5005 coils in a range of custom sizes, finishes, and tempers to perfectly fit our customers’ needs. Our commitment to precision, high-quality products, and timely delivery has established us as a trusted name in both the UAE and the global aluminium markets.

Aluminium 5005 Coils

Aluminium 5005 CR Coils

Aluminium 5005 HR Coils

Aluminium 5005 Coils Dealer in Dubai, Aluminium 5005 HR Coils Supplier in Dubai, Aluminium 5005 Coils in Ras Al Khaimah, Aluminium 5005 CR Coils Size Chart, Aluminium 5005 Coils Price in Ajman, Aluminium 5005 Coils Supplier in Jebel Ali, Aluminium 5005 Coils Stockist in Al Ain, Aluminium 5005 Hot Rolled Coils Exporter in UAE, Aluminium 5005 Coils Stockist in Dubai, Aluminium 5005 Coils Supplier in Al Ain

Aluminium 5005 Coils are primarily made up of Aluminium (around 97.1%), Magnesium (0.5–1.1%), along with small amounts of Iron, Silicon, Copper, Manganese, and Zinc. This alloy, which isn’t heat-treatable, boasts excellent resistance to atmospheric corrosion and is easy to weld. Its mechanical properties include a tensile strength ranging from 170 to 215 MPa, yield strength between 110 to 160 MPa (depending on the temper), and an elongation of 12 to 20%. This makes it suitable for moderate-strength applications while offering great formability and finishing characteristics.

Aluminium 5005 Coils Specification

Standards : ASTM B209 / ASME SB209

Temper : O,H14,H16,H18,H19,H22,H24

Thickness : 0.1-4

Width : coil

Length : 100-1600

Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.

Finish :Mill, Customer specific finish

Aluminum Coil Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating

Type : Hot-Rolled (HR) / Cold-Rolled (CR) Coil

Aluminium 5005 Coils Chemical Composition

Weight%	Al	Si	Fe	Cu	Mn	Cr	Mg	Zn	Others Each	Others Total
5005	Bal	0.30 max	0.70 max	0.20 max	0.20 max	0.10 max	0.50 / 1.10	0.25 max	0.05 max	0.15 max

Aluminium 5005 Coils Mechanical Properties

Material	Temper	Tensile Strength (N/mm²)	Yield Strength (N/mm²)	Elongation on 50mm (%)
Material	Temper	Tensile Strength (N/mm²)	Yield Strength (N/mm²)	0.5 mm	0.8 mm	1.3 mm	2.6mm
5005	0	95-145	–	18	20	21	22
5005	H12	125-170	80	4	5	6	8
5005	H14	145-185	100	3	3	5	6
5005	H18	185 min	165	1	2	3	3

Aluminium 5005 Coils Price in Ajman, Aluminium 5005 Hot Rolled Coils Weight Chart, Aluminium 5005 Cold Rolled Coils Supplier in Jebel Ali, Stockist of Aluminium 5005 Cold Rolled Coils in Al Ain, Aluminium 5005 Coils Supplier in UAE, Aluminium 5005 CR Coils Price List in Dubai, Aluminium 5005 Coils Supplier in Al Ain, Aluminium 5005 Hot Rolled Coils Exporter in Dubai, Aluminium 5005 Coils Exporter in UAE, Aluminium 5005 CR Coils Exporter in Ras Al Khaimah, Aluminium 5005 Coils in Ajman

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Aluminium 5005 Coils Manufacturer and Exporter in Dubai, UAE

Varun Sheets and Plates based in Dubai, UAE, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

Aluminium 5005 Coils Distributor in UAE, Aluminium 5005 Coils Supplier in Dubai, Aluminium 5005 Coils Weight Chart, Aluminium 5005 Hot Rolled Coils Exporter in Al Ain, Aluminium 5005 Coils Manufacturer in Dubai, Aluminium 5005 Coils Price List in Jebel Ali, Aluminium 5005 Coils Sizes in mm, Aluminium 5005 Hot Rolled Coils Distributor in Ras Al Khaimah, Aluminium 5005 Coils in Ajman

Aluminium 5005 Coils offer several advantages, including excellent corrosion resistance, especially in marine and coastal environments. This makes them ideal for outdoor applications like architectural cladding and marine structures. The alloy’s good formability allows for easy fabrication into various shapes, and its smooth surface finish enhances aesthetic appeal. Aluminium 5005 also boasts good weldability, making it suitable for diverse industrial processes. Additionally, it has a lightweight nature, contributing to energy efficiency and ease of handling. Its durability and resistance to oxidation further enhance its long-lasting performance in various applications.

Types of Aluminium 5005 Coils

Aluminium 5005 Coils Manufacturer in Dubai, Aluminium 5005 Hot Rolled Coils in Ras Al Khaimah, Aluminium 5005 CR Coils Supplier in Dubai, Aluminium 5005 Polished Exporter in Al Ain, Aluminium 5005 HR Coils Price List in Jebel Ali, Aluminium 5005 Cold Rolled Coils Distributor in Ras Al Khaimah, Aluminium 5005 Coils Supplier in Dubai, Aluminium 5005 Hot Rolled Coils Distributor in UAE, Aluminium 5005 Coils Sizes in mm

Are Custom Sizes Available for Aluminium 5005 Coils?

Yes, we offer custom sizes for Aluminium 5005 Coils to meet specific project needs. Our team at Varun Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@varunplates.ae

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Aluminium 5005 Coils

You’ll find Aluminium 5005 Coils commonly used in architectural and decorative projects like curtain walls, cladding panels, roofing, and facades, thanks to their anodizing quality and smooth finish. They’re also perfect for signage, kitchen equipment, electrical enclosures, and marine hardware where corrosion resistance is key. Additionally, 5005 coils are utilized in transportation, HVAC systems, and general sheet metal work due to their excellent formability and lightweight nature. Their durability, visual appeal, and ease of fabrication make them a versatile option across a wide range of industries.
